Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
22
TA-FE370/FE570
R907 1-260-328-11 CARBON 1K 5% 1/2W
(FE370)
R907 1-260-330-11 CARBON 1.5K 5% 1/2W
(FE570)
R908 1-260-328-11 CARBON 1K 5% 1/2W
R910 1-249-429-11 CARBON 10K 5% 1/4W
R912 1-249-429-11 CARBON 10K 5% 1/4W
R913 1-249-433-11 CARBON 22K 5% 1/4W
R916 1-249-419-11 CARBON 1.5K 5% 1/4W
< RELAY >
RY101 1-515-614-11 RELAY (FE570)
RY601 1-515-920-11 RELAY (24V)
< TERMINAL >
TM301 1-694-791-11 TERMINAL BOARD (SPEAKERS)
**************************************************************
1-681-421-11 POWER SW BOARD
****************
< CONNECTOR >
CN807 1-568-668-11 CONNECTOR, BOARD TO BOARD 6P
< LED >
D822 8-719-058-04 LED SEL5223S-TP15 (STANDBY)
< IC >
IC803 8-759-459-86 IC NJL64H400A
(REMOTE CONTROL RECEIVER)
< RESISTOR >
R833 1-249-421-11 CARBON 2.2K 5% 1/4W
< SWITCH >
S1 1-554-118-00 SWITCH, PUSH (1 KEY) (POWER)
**************************************************************
1-681-424-11 SPEAKER SW BOARD
*****************
< SWITCH >
S205 1-771-099-11 SWITCH, ROTARY (SPEAKERS)
**************************************************************
1-681-418-11 STANDBY BOARD
**************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
0 C1 1-113-924-11 CERAMIC 0.0047uF 20% 250V
C809 1-126-961-11 ELECT 2.2uF 20% 50V
C917 1-162-306-11 CERAMIC 0.01uF 30% 16V
C919 1-126-941-11 ELECT 470uF 20% 25V
< CONNECTOR >
* CN1 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN2 1-564-321-00 PIN, CONNECTOR 2P
CN3 1-564-321-00 PIN, CONNECTOR 2P
CN902 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D911 8-719-911-19 DIODE 1SS119-25
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-024-99 DIODE 11ES2-NTA2B
D915 8-719-024-99 DIODE 11ES2-NTA2B
D916 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0 F1 1-532-503-31 FUSE (T1.6AL/250V) (FE370)
0 F3 1-532-388-31 FUSE (T2AL/250V) (FE570)
< RESISTOR >
R914 1-249-385-11 CARBON 2.2 5% 1/6W
R915 1-247-807-31 CARBON 100 5% 1/4W
< RELAY >
0 RY1 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0 T2 1-433-735-11 TRANSFORMER, POWER
**************************************************************
1-681-420-11 VOLUME BOARD
**************
< VARIABLE RESISTOR >
RV202 1-241-426-11 RES, VAR, CARBON 100K/100K (VOLUME)
**************************************************************
MISCELLANEOUS
**************
60 1-773-025-11 WIRE (FLAT TYPE) (15 CORE)
0 104 1-575-651-21 CORD, POWER
0 CN4 1-526-794-11 OUTLET, AC (AEP)
0 CN5 1-526-794-11 OUTLET, AC (AEP)
0 CN6 1-526-794-11 OUTLET, AC (AEP)
0 T1 1-437-254-11 TRANSFORMER, POWER (FE570)
0 T1 1-437-255-11 TRANSFORMER, POWER (FE370)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
1-473-655-31 REMOTE COMMANDER (RM-S325)
4-233-885-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, GERMAN, SPANISH)
4-233-885-21 MANUAL, INSTRUCTION
(DUTCH, SWEDISH, ITALIAN, POLISH) (AEP)
4-981-643-01 COVER, BATTERY (for RM-S325)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN POWER SW SPEAKER SW STANDBY VOLUME
