TA-FE370/FE570
4
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
3-2. CASE
(Page 4)
3-3. FRONT PANEL ASSY
(Page 5)
3-4. MAIN BOARD
(Page 5)
SET
1 two screws
(case 3 TP2)
1 two screws
(case 3 TP2
)
1 two screws
(case 3 TP2)
2
2
3 case
