18
TA-FE370/FE570
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-681-425-11 AC OUTLET BOARD (AEP)
****************
1-533-217-41 HOLDER, FUSE
< FUSE >
0 F2 1-532-464-31 FUSE (T2.5AL/250V)
**************************************************************
A-4476-573-A CONTROL BOARD, COMPLETE (FE570)
A-4476-583-A CONTROL BOARD, COMPLETE (FE370)
*************************
< CAPACITOR >
C201 1-136-153-00 FILM 0.01uF 5% 50V
C202 1-136-165-00 MYLAR 0.1uF 5% 50V
C203 1-130-477-00 MYLAR 0.0033uF 5% 50V
C204 1-136-159-00 MYLAR 0.033uF 5% 50V
C205 1-130-473-00 MYLAR 0.0015uF 5% 50V
C251 1-136-153-00 FILM 0.01uF 5% 50V
C252 1-136-165-00 MYLAR 0.1uF 5% 50V
C253 1-130-477-00 MYLAR 0.0033uF 5% 50V
C254 1-136-159-00 MYLAR 0.033uF 5% 50V
C255 1-130-473-00 MYLAR 0.0015uF 5% 50V
C319 1-136-153-00 FILM 0.01uF 5% 50V
C801 1-126-795-11 ELECT 10uF 20% 50V
C802 1-126-916-11 ELECT 1000uF 20% 6.3V
C803 1-164-159-11 CERAMIC 0.1uF 50V
C806 1-162-294-31 CERAMIC 0.001uF 10% 50V
C807 1-126-795-11 ELECT 10uF 20% 50V
C808 1-164-159-11 CERAMIC 0.1uF 50V
C810 1-164-159-11 CERAMIC 0.1uF 50V
C811 1-126-795-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN802 1-770-396-11 HOUSING, CONNECTOR (PC BOARD) 3P
CN804 1-750-195-11 CONNECTOR, BOARD TO BOARD 6P
CN806 1-770-143-11 CONNECTOR, BOARD TO BOARD 6P
CN814 1-784-737-21 CONNECTOR, FFC 15P
< DIODE >
D801 8-719-985-59 DIODE HZS4CLL
D802 8-719-024-99 DIODE 11ES2-NTA2B
D803 8-719-911-19 DIODE 1SS119-25
D804 8-719-911-19 DIODE 1SS119-25
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
D805 8-719-911-19 DIODE 1SS119-25
D806 8-719-911-19 DIODE 1SS119-25
D807 8-719-058-64 LED SEL5823A-TP15 (SOURCE DIRECT)
D808 8-719-058-64 LED SEL5823A-TP15 (PHONO)
D809 8-719-058-64 LED SEL5823A-TP15 (TUNER)
D810 8-719-058-64 LED SEL5823A-TP15 (CD)
D811 8-719-058-64 LED SEL5823A-TP15 (AUX)
D812 8-719-058-64 LED SEL5823A-TP15 (TAPE2/MD)
D813 8-719-058-64 LED SEL5823A-TP15 (TAPE1/DAT)
D814 8-719-911-19 DIODE 1SS119-25
D816 8-719-911-19 DIODE 1SS119-25
D817 8-719-911-19 DIODE 1SS119-25
D819 8-719-911-19 DIODE 1SS119-25
D820 8-719-024-99 DIODE 11ES2-NTA2B
D821 8-719-058-64 LED SEL5823A-TP15 (EON LINK) (FE570)
D823 8-719-058-64 LED SEL5823A-TP15 (TAPE1 MONITOR)
(FE570)
< IC >
IC801 8-759-392-41 IC TMP47C103N-JP47
IC802 8-759-962-08 IC BA6208
< TRANSISTOR >
Q801 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q802 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q803 8-729-422-57 TRANSISTOR UN4111 (FE570)
Q804 8-729-422-57 TRANSISTOR UN4111
Q806 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q807 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q808 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q809 8-729-900-80 TRANSISTOR DTC114ES (FE570)
Q810 8-729-900-80 TRANSISTOR DTC114ES
Q811 8-729-900-80 TRANSISTOR DTC114ES
Q812 8-729-119-79 TRANSISTOR 2SC2785-FEK (FE570)
Q813 8-729-119-79 TRANSISTOR 2SC2785-FEK (FE570)
< RESISTOR >
R201 1-249-434-11 CARBON 27K 5% 1/4W
R202 1-249-421-11 CARBON 2.2K 5% 1/4W
R203 1-249-427-11 CARBON 6.8K 5% 1/4W
R204 1-249-415-11 CARBON 680 5% 1/4W
R205 1-249-421-11 CARBON 2.2K 5% 1/4W
R206 1-249-441-11 CARBON 100K 5% 1/4W
AC OUTLET
CONTROL
