TA-FE370/FE570
R208 1-247-874-11 CARBON 62K 5% 1/4W
R251 1-249-434-11 CARBON 27K 5% 1/4W
R252 1-249-421-11 CARBON 2.2K 5% 1/4W
R253 1-249-427-11 CARBON 6.8K 5% 1/4W
R254 1-249-415-11 CARBON 680 5% 1/4W
R255 1-249-421-11 CARBON 2.2K 5% 1/4W
R256 1-249-441-11 CARBON 100K 5% 1/4W
R258 1-247-874-11 CARBON 62K 5% 1/4W
R317 1-249-798-11 CARBON 680 5% 1/2W
R367 1-249-798-11 CARBON 680 5% 1/2W
R801 1-249-411-11 CARBON 330 5% 1/4W
R802 1-247-807-31 CARBON 100 5% 1/4W
R803 1-249-429-11 CARBON 10K 5% 1/4W
R804 1-249-429-11 CARBON 10K 5% 1/4W
R805 1-249-425-11 CARBON 4.7K 5% 1/4W
R806 1-247-843-11 CARBON 3.3K 5% 1/4W
R807 1-247-843-11 CARBON 3.3K 5% 1/4W
R808 1-249-429-11 CARBON 10K 5% 1/4W
R809 1-249-429-11 CARBON 10K 5% 1/4W
R810 1-249-429-11 CARBON 10K 5% 1/4W
R811 1-249-429-11 CARBON 10K 5% 1/4W
R812 1-249-401-11 CARBON 47 5% 1/4W
R814 1-249-413-11 CARBON 470 5% 1/4W
(FE570)
R814 1-249-429-11 CARBON 10K 5% 1/4W
(FE370)
R815 1-249-429-11 CARBON 10K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-429-11 CARBON 10K 5% 1/4W
R819 1-249-429-11 CARBON 10K 5% 1/4W
R820 1-249-429-11 CARBON 10K 5% 1/4W
R821 1-249-429-11 CARBON 10K 5% 1/4W
R822 1-249-429-11 CARBON 10K 5% 1/4W
R823 1-249-433-11 CARBON 22K 5% 1/4W
R824 1-249-429-11 CARBON 10K 5% 1/4W
R826 1-249-401-11 CARBON 47 5% 1/4W
R827 1-249-393-11 CARBON 10 5% 1/4W
(FE570)
R828 1-249-429-11 CARBON 10K 5% 1/4W
R829 1-249-429-11 CARBON 10K 5% 1/4W
R830 1-249-429-11 CARBON 10K 5% 1/4W
R831 1-249-401-11 CARBON 47 5% 1/4W
(FE570)
R834 1-249-413-11 CARBON 470 5% 1/4W
R835 1-249-429-11 CARBON 10K 5% 1/4W
(FE570)
R836 1-249-425-11 CARBON 4.7K 5% 1/4W
(FE570)
R837 1-249-413-11 CARBON 470 5% 1/4W
R838 1-249-413-11 CARBON 470 5% 1/4W
(FE570)
< VARIABLE RESISTOR >
RV201 1-223-396-21 RES, VAR, CARBON 100K/100K (BALANCE)
RV203 1-223-397-21 RES, VAR, CARBON 100K/100K (TONE BASS)
RV204 1-223-397-21 RES, VAR, CARBON 100K/100K
(TONE TREBLE)
< SWITCH >
S202 1-571-828-11 SWITCH, PUSH (1 KEY) (SOURCE DIRECT)
S801 1-692-974-11 SWITCH, ROTARY (INPUT SELECTOR)
S802 1-771-349-21 SWITCH, KEYBOARD (TAPE1 MONITOR)
(FE570)
S803 1-571-112-21 SWITCH, PUSH (1 KEY) (EON LINK) (FE570)
< VIBRATOR >
X801 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
**************************************************************
1-681-422-11 HEADPHONE BOARD
*****************
< CONNECTOR >
CN803 1-770-387-11 PIN, CONNECTOR (PC BOARD) 3P
< JACK >
J501 1-750-735-11 JACK (LARGE TYPE) (PHONES)
**************************************************************
1-681-423-11 LOUDNESS BOARD
****************
< CONNECTOR >
CN805 1-750-186-11 CONNECTOR, BOARD TO BOARD 6P
< SWITCH >
S201 1-571-112-21 SWITCH, PUSH (1 KEY) (LOUDNESS)
**************************************************************
A-4476-571-A MAIN BOARD, COMPLETE (FE570)
A-4476-581-A MAIN BOARD, COMPLETE (FE370)
*********************
< CAPACITOR >
C101 1-162-282-31 CERAMIC 100PF 10% 50V
C102 1-162-286-31 CERAMIC 220PF 10% 50V
C103 1-126-963-11 ELECT 4.7uF 20% 50V
C104 1-104-660-11 ELECT 47uF 20% 16V
C105 1-162-282-31 CERAMIC 100PF 10% 50V
C106 1-130-480-00 MYLAR 0.0056uF 5% 50V
C107 1-130-473-00 MYLAR 0.0015uF 5% 50V
C108 1-126-964-11 ELECT 10uF 20% 50V
C109 1-126-964-11 ELECT 10uF 20% 50V
C110 1-126-963-11 ELECT 4.7uF 20% 50V
(FE570)
C112 1-162-294-31 CERAMIC 0.001uF 10% 50V
C114 1-162-306-11 CERAMIC 0.01uF 30% 16V
C115 1-126-963-11 ELECT 4.7uF 20% 50V
C151 1-162-282-31 CERAMIC 100PF 10% 50V
C152 1-162-286-31 CERAMIC 220PF 10% 50V
C153 1-126-963-11 ELECT 4.7uF 20% 50V
C154 1-104-660-11 ELECT 47uF 20% 16V
C155 1-162-282-31 CERAMIC 100PF 10% 50V
C156 1-130-480-00 MYLAR 0.0056uF 5% 50V
C157 1-130-473-00 MYLAR 0.0015uF 5% 50V
C158 1-126-964-11 ELECT 10uF 20% 50V
CONTROL HEADPHONE LOUDNESS MAIN
