Sony TA-FE370 - ICs, Connectors, Jacks, and Coils

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
20
TA-FE370/FE570
C301 1-126-964-11 ELECT 10uF 20% 50V
C302 1-162-290-31 CERAMIC 470PF 10% 50V
C303 1-162-282-31 CERAMIC 100PF 10% 50V
C305 1-126-933-11 ELECT 100uF 20% 16V
C306 1-126-967-11 ELECT 47uF 20% 50V
(FE370)
C306 1-128-552-11 ELECT 47uF 20% 63V
(FE570)
C307 1-126-965-11 ELECT 22uF 20% 50V
(FE370)
C307 1-128-551-11 ELECT 22uF 20% 63V
(FE570)
C308 1-126-965-11 ELECT 22uF 20% 50V
(FE370)
C308 1-128-551-11 ELECT 22uF 20% 63V
(FE570)
C309 1-126-965-11 ELECT 22uF 20% 50V
(FE370)
C309 1-128-551-11 ELECT 22uF 20% 63V
(FE570)
C310 1-126-969-11 ELECT 220uF 20% 50V
(FE370)
C310 1-128-553-11 ELECT 220uF 20% 63V
(FE570)
C311 1-136-165-00 MYLAR 0.1uF 5% 50V
C312 1-136-165-00 MYLAR 0.1uF 5% 50V
C313 1-104-660-11 ELECT 47uF 20% 16V
C314 1-162-211-11 CERAMIC 33PF 5% 50V
C315 1-126-969-11 ELECT 220uF 20% 50V
(FE370)
C315 1-128-553-11 ELECT 220uF 20% 63V
(FE570)
C351 1-126-964-11 ELECT 10uF 20% 50V
C352 1-162-290-31 CERAMIC 470PF 10% 50V
C353 1-162-282-31 CERAMIC 100PF 10% 50V
C355 1-126-933-11 ELECT 100uF 20% 16V
C356 1-126-967-11 ELECT 47uF 20% 50V
(FE370)
C356 1-128-552-11 ELECT 47uF 20% 63V
(FE570)
C361 1-136-165-00 MYLAR 0.1uF 5% 50V
C362 1-136-165-00 MYLAR 0.1uF 5% 50V
C363 1-104-660-11 ELECT 47uF 20% 16V
C364 1-162-211-11 CERAMIC 33PF 5% 50V
C601 1-126-961-11 ELECT 2.2uF 20% 50V
C602 1-126-934-11 ELECT 220uF 20% 10V
C603 1-104-660-11 ELECT 47uF 20% 16V
C812 1-164-159-11 CERAMIC 0.1uF 50V
(FE570)
C900 1-136-153-00 FILM 0.01uF 5% 50V
C901 1-137-397-11 MYLAR 0.047uF 5% 100V
C902 1-137-397-11 MYLAR 0.047uF 5% 100V
C903 1-125-793-11 ELECT 8200uF 20% 56V
(FE570)
C903 1-125-815-11 ELECT 6800uF 20% 50V
(FE370)
C904 1-125-793-11 ELECT 8200uF 20% 56V
(FE570)
C904 1-125-815-11 ELECT 6800uF 20% 50V
(FE370)
C905 1-126-968-11 ELECT 100uF 20% 50V
(FE370)
C905 1-128-576-11 ELECT 100uF 20% 63V
(FE570)
C906 1-126-968-11 ELECT 100uF 20% 50V
(FE370)
C906 1-128-576-11 ELECT 100uF 20% 63V
(FE570)
C907 1-161-494-00 CERAMIC 0.022uF 25V
C908 1-104-660-11 ELECT 47uF 20% 16V
C909 1-104-660-11 ELECT 47uF 20% 16V
C910 1-126-933-11 ELECT 100uF 20% 16V
C911 1-126-933-11 ELECT 100uF 20% 16V
C912 1-136-153-00 FILM 0.01uF 5% 50V
C913 1-126-964-11 ELECT 10uF 20% 50V
C915 1-126-933-11 ELECT 100uF 20% 16V
C916 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CN811 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN812 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
CN813 1-566-212-11 PIN, CONNECTOR 3P (EON CONTROL IN)
(FE570)
CN815 1-784-776-11 CONNECTOR, FFC 15P
CN901 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D101 8-719-911-19 DIODE 1SS119-25 (FE570)
D301 8-719-911-19 DIODE 1SS119-25
D302 8-719-911-19 DIODE 1SS119-25
D351 8-719-911-19 DIODE 1SS119-25
D352 8-719-911-19 DIODE 1SS119-25
D601 8-719-911-19 DIODE 1SS119-25
D901 8-719-302-38 DIODE RBV-602-01
D902 8-719-986-25 DIODE HZS12A2LTA
D903 8-719-986-25 DIODE HZS12A2LTA
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-024-99 DIODE 11ES2-NTA2B
D906 8-719-024-99 DIODE 11ES2-NTA2B
D907 8-719-024-99 DIODE 11ES2-NTA2B
D909 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC101 8-759-805-13 IC LC7821
IC102 8-759-184-02 IC NJM2068L-D
IC301 8-749-921-04 IC STK4211MK2 (FE370)
IC301 8-749-922-65 IC STK4221MK2 (FE570)
IC601 8-759-111-68 IC uPC1237HA
IC901 8-759-708-05 IC NJM78L05A
< JACK >
J101 1-794-981-11 JACK, PIN 4P (PHONO IN, TUNER IN)
J102 1-793-776-12 JACK, PIN 6P
(CD IN, AUX IN, TAPE2/MD RECOUT)
J103 1-793-776-12 JACK, PIN 6P (TAPE2/MD IN,
TAPE1/DAT RECOUT, TAPE1/DAT IN)
< COIL >
L301 1-420-872-00 COIL, AIR-CORE
MAIN
