Specifications
35
Specifications
Picture performance
Panel OLED panel
Picture size (diagonal)
PVM-2541A: 623.4 mm (24
5
/8 inches)
PVM-1741A: 419.7 mm (16
5
/8 inches)
Effective picture size (H × V)
PVM-2541A: 543.4 × 305.6 mm
(21
1
/2 × 12
1
/8 inches)
PVM-1741A: 365.8 × 205.7 mm
(14
1
/2 × 8
1
/8 inches)
Resolution (H × V)
1920 × 1080 pixels (Full HD)
Aspect 16:9
Pixel efficiency 99.99%
Panel drive RGB 10-bit
Viewing angle (Panel specification)
89º/89º/89º/89º (typical)
(up/down/left/right, contrast > 10:1)
Normal scan 0% scan
Over scan 5% over scan
Color temperature
D65, D93
Warm-up time Approx. 30 minutes
To provide stable picture quality, turn
on the power of the monitor and
leave it in this state for more than 30
minutes.
Input
Composite input (NTSC/PAL) connector
BNC type (1)
1 Vp-p ± 3 dB sync negative
SDI input connector
BNC type (2)
HDMI input connector
HDMI (1)
HDCP correspondence
Audio input connector
Stereo mini jack (1)
–5 dBu
47 kΩ or higher
Remote input connector
Parallel remote
Modular connector 8-pin (1)
Serial remote
RJ-45 modular connector (1)
(ETHERNET, 10BASE-T/
100BASE-TX)
DC IN connector
PVM-1741A: XLR 4-pin (male) (1)
DC 12 V (output impedance 0.05 Ω or
less)
Output
SDI (3G/HD/SD) output connector
BNC type (1)
Output signal amplitude: 800 mVp-p
±10%
Output impedance: 75 Ω unbalanced
Composite output connector
BNC type (1)
Loop-through, with 75 Ω automatic
terminal function
Audio monitor output connector
Stereo mini jack (1)
Built-in speaker output
1.0 W Monaural
Headphones output connector
Stereo mini jack (1)
General
Power PVM-2541A: AC 100 to 240 V, 1.4 A
to 0.6 A, 50/60 Hz
PVM-1741A: AC 100 to 240 V, 1.0 A
to 0.5 A, 50/60 Hz
DC 12 V, 7.0 A
Power consumption
PVM-2541A:
Approx. 130 W (max.)
Approx. 88 W (average power
consumption in the default status)
PVM-1741A:
Approx. 90 W (max.)
Approx. 70 W (average power
consumption in the default status)
Inrush current
PVM-2541A:
(1) Maximum possible inrush current
at initial switch-on (Voltage
changes caused by manual
switching):
40 A peak, 8 A r.m.s. (240V AC)
(2) Inrush current after a mains
interruption of five seconds
(Voltage changes caused at zero-
crossing):
40 A peak, 8 A r.m.s. (240V AC)
PVM-1741A:
(1) Maximum possible inrush current
at initial switch-on (Voltage
changes caused by manual
switching):
35 A peak, 7 A r.m.s. (240V AC)
(2) Inrush current after a mains
interruption of five seconds
(Voltage changes caused at zero-
crossing):
35 A peak, 7 A r.m.s. (240V AC)
Operating conditions
Temperature
