10
Numeric buttons
Function buttons
Up to a total of three controller units can be
simultaneously connected to this unit.
Button Operations
1 to 9 button Turns on/off functions assigned to the
numeric buttons from 1 to 9 on the
controller, or switches the settings in a
sequential order.
The factory default settings are
following:
1 button: Ch.1
2 button: Ch.2
3 button: Ch.3
4 button: Ch.4
5 button: WFM
6 button: Native Scan
7 button: Internal Signal
8 button: Int. Signal Pattern
9 button: Marker
You can assign the various functions
under “F/Num Key Setting” (page 34)
of “Controller” in the “F Key Setting”
menu.
Ent button Operates similar to the ENTER button
on the controller.
Button Operations
F1 to F16 button Turns on or off functions assigned to
the function buttons on the controller.
The following functions are available.
Mono, Blue Only, R Off, G Off, B Off,
Native Scan, Pixel Zoom, Marker,
Aspect Marker, Area Marker1, Area
Marker2, Center Marker, Aspect
Marker-Line, Asp. Blank.-Black, Asp.
Blank.-Half, ALM, Time Code
