52
Dimensions
PVM-X2400
Front
Rear
Side
Bottom
Unit: mm (inches)
Mass: Approx. 10.5 kg (23 lb 2.4 oz)
4×M4
: Exhaust vents
: Intake vents
4×M4
When installing on a vehicle,
secure the unit using the M4 screw
holes on the side.
302 × 43 (12 × 1
3
/4)
70.3 (2
7
/8) 43 (1
3
/4)
429.2 (17)
: Intake vents
