Sony TRIMASTER PVM-X2400 - Supported Signal Formats - HDMI Continued II; HDMI Signal Formats Continued

51
1) Also compatible with the frame rate 1/1.001.
2) This signal is described as “equivalent to the 4K signal” in this manual.
3) “Enhanced Format” must be selected in the “HDMI In. Setting” (page 28). Also, when using this input signal, use the Premium High-
Speed HDMI cable. (30P, 25P, 24P signals are only for the 4:4:4 RGB/YCbCr 10/12bit signal.)
4) The 4:4:4(YCbCr)12/10bit signal is displayed after converting to the 4:2:2(YCbCr)12/10bit signal. If it is not displayed correctly, use the
4:4:4(YCbCr)8bit signal or 4:2:2(YCbCr)12bit signal as the input signal.
5) The 4:4:4(RGB)12/10bit signal is displayed after converting to the 4:2:2(YCbCr)12/10bit signal. If it is not displayed correctly, use the
4:4:4(RGB)8bit signal or 4:2:2(YCbCr)12bit signal as the input signal. However, when AVI Info (signal information) cannot be detected
and/or “RGB/YCC Range” is set to “Full,” it is displayed as the 4:4:4(RGB)8bit signal if the input signal is determined as the Limited
signal.
6) This signal system is not described in EDID (Extended Display Identification Data).
3840 × 2160/24P
1) 2)
4 : 4 : 4 (RGB) 12/10/8bit
3) 5)
4 : 4 : 4 (YCbCr) 12/10/8bit
3) 4)
4 : 2 : 2 (YCbCr) 12bit
4096 × 2160/30P
1) 2)
4 : 4 : 4 (RGB) 12/10/8bit
3) 5)
4 : 4 : 4 (YCbCr) 12/10/8bit
3) 4)
4 : 2 : 2 (YCbCr) 12bit
4096 × 2160/25P
2)
4 : 4 : 4 (RGB) 12/10/8bit
3) 5)
4 : 4 : 4 (YCbCr) 12/10/8bit
3) 4)
4 : 2 : 2 (YCbCr) 12bit
4096 × 2160/24P
1) 2)
4 : 4 : 4 (RGB) 12/10/8bit
3) 5)
4 : 4 : 4 (YCbCr) 12/10/8bit
3) 4)
4 : 2 : 2 (YCbCr) 12bit
3840 × 2160/60P
1) 2)
4 : 4 : 4 (RGB) 8bit
3)
4 : 4 : 4 (YCbCr) 8bit
3)
4 : 2 : 2 (YCbCr) 12bit
3)
4 : 2 : 0 (YCbCr) 10/8bit
3840 × 2160/50P
2)
4 : 4 : 4 (RGB) 8bit
3)
4 : 4 : 4 (YCbCr) 8bit
3)
4 : 2 : 2 (YCbCr) 12bit
3)
4 : 2 : 0 (YCbCr) 10/8bit
4096 × 2160/60P
1) 2)
4 : 4 : 4 (RGB) 8bit
3)
4 : 4 : 4 (YCbCr) 8bit
3)
4 : 2 : 2 (YCbCr) 12bit
3)
4 : 2 : 0 (YCbCr) 10/8bit
4096 × 2160/50P
2)
4 : 4 : 4 (RGB) 8bit
3)
4 : 4 : 4 (YCbCr) 8bit
3)
4 : 2 : 2 (YCbCr) 12bit
3)
4 : 2 : 0 (YCbCr) 10/8bit
800 × 600/60P
4 : 4 : 4 (RGB) 12/10/8bit
4 : 4 : 4 (YCbCr) 12/10/8bit
4 : 2 : 2 (YCbCr) 12bit
1024 × 768/60P
4 : 4 : 4 (RGB) 12/10/8bit
4 : 4 : 4 (YCbCr) 12/10/8bit
4 : 2 : 2 (YCbCr) 12bit
Signal System Signal Structure
