REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-E400/E400E/E400P
7-11
<RELAY>
RY6010 1-755-279-11 RELAY, AC POWER
RY6020 1-755-318-11 RELAY, POWER
<SWITCH>
S6010 1-771-727-11 SWITCH, AC POWER PUSH (POWER)
<SPARK GAP>
SG901 1-517-499-21 GAP, SPARK
SG902 1-519-422-11 GAP, SPARK
SG903 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 1-435-188-11 TRANSFORMER, FERRITE (HDT)
T502 1-411-594-11 INDUCTOR 5mH
T503 1-435-140-11 TRANSFORMER, FERRITE (LCT)
T504 1-431-413-21 TRANSFORMER, FERRITE (HST)
T602 1-435-141-11 TRANSFORMER, CONVERTER (SRT)
T701 1-435-142-11 TRANSFORMER, FERRITE (DFT)
T901 0 X-4560-174-1 TRANSFORMER ASSY, FLYBACK
(NX4700//J1E4)
T902 1-419-345-11 COIL, CHOKE 500uH
<THERMISTOR>
TH6000 1-809-260-11 THERMISTOR, POWER
TH6010 1-803-540-11 THERMISTOR
<VARISTOR>
VA6010 1-801-268-51 VARISTOR TNR14V471K660
<CRYSTAL>
X1001 1-567-890-11 VIBRATOR, CRYSTAL (8MHz)
*******************************************************************************
H BOARD, COMPLETE
****************************
<CAPACITOR>
C2002 1-126-786-11 ELECT 47uF 20% 16V
<CONNECTOR>
CN2001* 1-564-511-11 PLUG, CONNECTOR 8P
<DIODE>
D2001 8-719-064-11 DIODE SPR-325MVW (POWER)
D2004 8-719-109-89 ZENER DIODE RD5.6ESB2
<FERRITE BEAD>
FB2001 1-412-911-11 FERRITE 1.1uH
FB2002 1-412-911-11 FERRITE 1.1uH
FB2003 1-412-911-11 FERRITE 1.1uH
FB2004 1-412-911-11 FERRITE 1.1uH
FB2005 1-412-911-11 FERRITE 1.1uH
<TRANSISTOR>
Q2001 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q2002 8-729-119-76 TRANSISTOR 2SA1175-HFE
<RESISTOR>
R2001 1-249-422-11 CARBON 2.7K 5% 1/4W
R2002 1-249-429-11 CARBON 10K 5% 1/4W
R2003 1-249-429-11 CARBON 10K 5% 1/4W
R2004 1-215-411-00 METAL 390 1% 1/4W
R2005 1-215-417-00 METAL 680 1% 1/4W
R2006 1-249-411-11 CARBON 330 5% 1/4W
R2007 1-249-413-11 CARBON 470 5% 1/4W
R2008 1-249-415-11 CARBON 680 5% 1/4W
R2009 1-247-831-91 CARBON 1K 5% 1/4W
R2011 1-249-427-11 CARBON 6.8K 5% 1/4W
R2012 1-249-429-11 CARBON 10K 5% 1/4W
<SWITCH>
S2002 1-771-734-11 SWITCH, TACTILE (MENU)
S2003 1-762-196-21 SWITCH, TACT (RESET)
*******************************************************************************
N BOARD, COMPLETE
****************************
<CAPACITOR>
C801 1-113-340-11 ELECT 47uF 20% 25V
C803 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C809 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C810 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C811 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C812 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C813 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C814 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
