REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-E400/E400E/E400P
7-12
N
C817 1-119-941-91 ELECT 470uF 20% 6.3V
C818 1-113-340-11 ELECT 47uF 20% 25V
C819 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C820 1-119-941-91 ELECT 470uF 20% 6.3V
C821 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C822 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C823 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C824 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C825 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C826 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C827 1-119-941-91 ELECT 470uF 20% 6.3V
C828 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C829 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C830 1-113-340-11 ELECT 47uF 20% 25V
C832 1-131-722-91 ELECT 100uF 20% 6.3V
C833 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C835 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C837 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C838 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C839 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C840 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C841 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
<CONNECTOR>
CN801 1-793-585-11 PIN, CONNECTOR (PC BOARD) 15P
CN802 1-793-586-11 PIN, CONNECTOR (PC BOARD) 15P
<DIODE>
D802 8-719-049-09 DIODE ISS367-T3 SONY
<FERRITE BEAD>
FB801 1-543-960-22 FERRITE
FB802 1-216-295-91 SHORT 0
FB809 1-543-963-22 FERRITE
FB810 1-543-963-22 FERRITE
<IC>
IC801 8-759-589-56 IC CXD9517Q
IC802 8-759-569-45 IC LD1117S33TR
IC803 8-759-502-82 IC LM324M
<CHIP CONDUCTOR>
JR801 1-216-295-91 SHORT 0
JR802 1-216-295-91 SHORT 0
<TRANSISTOR>
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q804 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q805 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
<RESISTOR>
R801 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R802 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R803 1-216-033-00 RES,CHIP 220 5% 1/10W
R804 1-216-033-00 RES,CHIP 220 5% 1/10W
R805 1-216-033-00 RES,CHIP 220 5% 1/10W
R806 1-216-033-00 RES,CHIP 220 5% 1/10W
R807 1-216-033-00 RES,CHIP 220 5% 1/10W
R808 1-216-033-00 RES,CHIP 220 5% 1/10W
R809 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R810 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R811 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R812 1-216-049-91 RES,CHIP 1K 5% 1/10W
R813 1-216-049-91 RES,CHIP 1K 5% 1/10W
R814 1-216-031-00 RES,CHIP 180 5% 1/10W
R815 1-216-073-00 RES,CHIP 10K 5% 1/10W
R816 1-218-768-11 METAL CHIP 470K 0.5% 1/10W
R818 1-216-049-91 RES,CHIP 1K 5% 1/10W
R819 1-216-049-91 RES,CHIP 1K 5% 1/10W
R820 1-216-049-91 RES,CHIP 1K 5% 1/10W
R821 1-216-049-91 RES,CHIP 1K 5% 1/10W
R822 1-216-049-91 RES,CHIP 1K 5% 1/10W
R823 1-216-667-11 METAL CHIP 4.7K 0.5% 1/10W
R824 1-216-073-00 RES,CHIP 10K 5% 1/10W
R825 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R826 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R827 1-216-073-00 RES,CHIP 10K 5% 1/10W
R828 1-216-667-11 METAL CHIP 4.7K 0.5% 1/10W
R829 1-216-049-91 RES,CHIP 1K 5% 1/10W
R830 1-216-049-91 RES,CHIP 1K 5% 1/10W
R831 1-216-033-00 RES,CHIP 220 5% 1/10W
R832 1-216-025-91 RES,CHIP 100 5% 1/10W
R833 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R834 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R835 1-216-089-91 RES,CHIP 47K 5% 1/10W
R836 1-216-049-91 RES,CHIP 1K 5% 1/10W
R837 1-216-648-11 METAL CHIP 750 0.5% 1/10W
R838 1-216-041-00 RES,CHIP 470 5% 1/10W
R839 1-216-117-00 RES,CHIP 680K 5% 1/10W
R840 1-216-650-11 METAL CHIP 910 0.5% 1/10W
R841 1-216-089-91 RES,CHIP 47K 5% 1/10W
R842 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R843 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R844 1-216-017-91 RES,CHIP 47 5% 1/10W
R846 1-216-025-91 RES,CHIP 100 5% 1/10W
R847 1-216-667-11 METAL CHIP 4.7K 0.5% 1/10W
R851 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R852 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R853 1-216-049-00 RES,CHIP 1K 5% 1/10W
R855 1-216-105-91 RES,CHIP 220K 5% 1/10W
R856 1-216-073-00 RES,CHIP 10K 5% 1/10W
R857 1-216-049-91 RES,CHIP 1K 5% 1/10W
R858 1-216-073-00 RES,CHIP 10K 5% 1/10W
R859 1-216-025-91 RES,CHIP 100 5% 1/10W
R860 1-216-025-91 RES,CHIP 100 5% 1/10W
R863 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
