Sony TRINITRON GDM-500PS - Disassembly Procedures

GDM-500PS/500PST/500PST9
2-1. CABINET REMOVAL
SECTION 2
DISASSEMBLY
2-2. D BOARD REMOVAL
2-1
Top cover
Four screws
(+ BVTT 4 x 8)
Four screws
(+ BVTT 4 x 8)
Video shield
4
5
6
8
Screw cover
Cabinet
3
Four screws
(+ BVTP 4 x 16)
2
1
Two claws
Screw cover
7
Two screws
(+ BVTT 4 x 8)
Two screws
(+ BVTP 3 x 10)
D board
Screw
(+ P 3.5 x 20)
Open the D block in the direction
of the arrow . and remove of
the arrow .
Three hooks
6
A
B
A
B
Screw
(+ BVTT 4 x 8)
1
2
3
4 5
