Sony TRINITRON GDM-500PS - Timing Specification

GDM-500PS/500PST/500PST9
– 4 –
MODE AT PRODUCTION MODE 1 MODE 2
RESOLUTION 738 X 414 1600 X 1200
CLOCK 28.322 MHz 229.500 MHz
— HORIZONTAL —
H-FREQ 31.469 kHz 106.250 kHz
usec usec
H. TOTAL 31.777 9.412
H. BLK 5.720 2.440
H. FP 0.318 0.279
H. SYNC 3.813 0.837
H. BP 1.589 1.325
H. ACTIV 26.057 6.972
— VERTICAL —
V. FREQ(HZ) 70.087 Hz 85.000 Hz
lines lines
V. TOTAL 449 1250
V. BLK 35 50
V. FP 5 1
V. SYNC 2 3
V. BP 28 46
V. ACTIV 414 1200
— SYNC —
INT(G) NO NO
EXT(H/V)/POLARITY YES N/P YES P/P
EXT(CS)/POLARITY NO NO
INT/NON INT NON INT NON INT
97.9.10 VER.
TIMING SPECIFICATION
