Sony TRINITRON GDM-500PS - 7 Electrical Parts List

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-500PS/500PST/500PST9
7-1
* 8-933-275-00 A BOARD, COMPLETE
* 8-933-364-00 A3 BOARD, COMPLETE
*****************************
Note: A complete board and A3 complete board
have interchangeability though it is a little
different because the material of the circuit
board is different.
4-382-854-11 SCREW (M3X10), P, SW (+) (IC403)
<CAPACITOR>
C101 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C102 1-104-664-11 ELECT 47µF 20% 25V
C103 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C104 1-104-664-11 ELECT 47µF 20% 25V
C105 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C106 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C107 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C108 1-107-903-11 ELECT 2.2µF 20% 50V
C109 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
(A BOARD)
C109 1-163-239-11 CERAMIC CHIP 33pF 5% 50V
(A3 BOARD)
C110 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C111 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C112 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C113 1-216-097-91 RES, CHIP 100K 5% 1/10W
(A BOARD)
C115 1-104-514-11 FILM 0.22µF 10% 250V
C120 1-107-949-11 ELECT 2.2µF 20% 200V
C121 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C122 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C127 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C130 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C201 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C202 1-104-664-11 ELECT 47µF 20% 25V
C203 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C204 1-104-664-11 ELECT 47µF 20% 25V
C205 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C206 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C207 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C208 1-107-903-11 ELECT 2.2µF 20% 50V
C209 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C210 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
NOTE:
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
A or A3
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
C211 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C212 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C213 1-216-097-91 RES, CHIP 100K 5% 1/10W
(A BOARD)
C215 1-104-514-11 FILM 0.22µF 10% 250V
C217 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C220 1-107-949-11 ELECT 2.2µF 20% 200V
C221 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C222 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C230 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C301 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C302 1-104-664-11 ELECT 47µF 20% 25V
C303 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C304 1-104-664-11 ELECT 47µF 20% 25V
C305 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C306 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C307 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C308 1-107-903-11 ELECT 2.2µF 20% 50V
C309 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
(A BOARD)
C309 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
(A3 BOARD)
C310 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C311 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C312 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C313 1-216-097-91 RES, CHIP 100K 5% 1/10W
(A BOARD)
C315 1-104-514-11 FILM 0.22µF 10% 250V
C317 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C319 1-107-888-11 ELECT 47µF 20% 25V
C320 1-107-949-11 ELECT 2.2µF 20% 200V
C321 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C322 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C330 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C401 1-126-964-11 ELECT 10µF 20% 50V
C402 1-104-664-11 ELECT 47µF 20% 25V
C403 1-104-664-11 ELECT 47µF 20% 25V
C404 1-126-964-11 ELECT 10µF 20% 50V
C405 1-163-227-11 CERAMIC CHIP 10pF 0.5PF 50V
C407 1-126-964-11 ELECT 10µF 20% 50V
C408 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C409 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C410 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
GDM-500PS/500PST/500PST9
