The components identified by
shading and marked “4, are critical
for safety.
Replace only with the part number
specified.
REF.NO. PART NO. DESCRIPTION _ _ REMARK
< FERRITE BEAD >
FB1001 1-410-397-21 FERRITE BEAD INDUCTOR 1.10H
< IC >
1c1001 8-759-391-40 IC P87C750EBPN
< TRANSISTOR >
Q1001 8-729-119-78 TRANSISTOR 28C1740S-RT
< RESISTOR >
R1001 1-249-417-11 CARBON 1K 5% 1/4W
R1002 1-249-417-11 CARBON 1K 5% 1/40
R1003 1~249-417-11 CARBON 1K 5% 1/4W
R1004 1-247-863-91 CARBON 22K 5% 1/40
R1005 1-247-807-31 CARBON 100 5% 1/4W
R1011 1-247-807-31 CARBON ~ 100 5% 1/4W
R1016 1-249-399-11 CARBON 33 5% 1/4W
R1017 1-249-482-11 CARBON 8.2K 5% 1/40
R1018 1-249-429-11 CARBON 10K 5% 1/40
< CRYSTAL >
X1001 1-578-774-11 VIBRATOR, CRYSTAL
