Sony TRINITRON KV-28WF3A - 2 Disassembly; Rear Cover Removal; Chassis Assy Removal; Service Position

17
KV-28WF3/32WF3
SECTION 2
DISASSEMBLY
2 Rear Cover
1 7 Screws BTV 4x16
2-1. REAR COVER REMOVAL
2-2. CHASSIS ASSY REMOVAL
2-4. G BOARD REMOVAL 2-3. SERVICE POSITION
To release, push
the claws in the direction of
the arrow as indicated.
