Sony TRINITRON KV-28WF3A - Page 24

KV-28WF3/32WF3
25
SDA9361 (VIDEO PROC)
Item No Adjustment item Data Amount
1 V Size Adj
2 V Centre Adj
3 V Linearity Adj
4 S Correction Adj
5 H Size Adj
6 Pin Amp Adj
7 Up Corner Correction Adj
8 Low Corner Correction Adj
9 V Bow Adj
10 Pin Phase Adj
11 V Angle Adj
12 HDE ON
13 VR 0
14 RABL ON
15 Blk Dis OFF
16 2FH 2xLine Freq ON
17 Stand-by Mode OFF
18 Vertical ON
19 BSE Blk Select OFF
20 SSE Start Scan OFF
21 SRSE Start Red Scan OFF
22 GBE Guard Board OFF
23 STE Scan time table OFF
24 NSA Self Adaption ON
25 V EHT comp 28” = 111
32” = 90
26 H EHT comp 28” = 85
32” = 90
27 H Centre 32
28 PWM Start 0
Item No Adjustment item Data Amount
29 D/A 0
30 V Blk Time 27
31 H Blk Time 41
32 Start V Scan 0
33 H Blk Phase 61
34 V Scan width 0 0
35 V Scan width 1 0
36 Guard Band 0
37 Start Red Scan 0
38 Number fields 1
39 NI Non Interface OFF
40 NR V Sync Noise Red OFF
41 SSC with VBL ON
42 Min lines/field 0
43 Max lines/field 0
44 AFC EHT comp 0
45 PLL Freq 6
46 VCR ON
47 Gen Mode OFF
48 HSWID ON
49 Int H Phase Adj
50 PWM width 0
51 Noisy VCR OFF
52 Killzip OFF
53 tc3rd OFF
54 Bandgap 4 off OFF
55 Bandgap off OFF
56 Bandgap 0
