KV-28WF3/32WF3
REF. NO. PART.NO DESCRIPTION REMARKREF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
93
***************************************************************************************
61 *4-203-128-11 SHEET BLOTTING
62 4-203-870-01 SUPPORTER, CRT
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
4-203-098-01 SUPPORTER, CRT
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
63 1-505-782-11 SPEAKER (7X13CM)
64 £ 8-737-781-05 PICTURE TUBE (SD-284T)(W66LGY060X)
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
£ 8-735-037-05 PICTURE TUBE (SD-297)(W76LHT060X)
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
65 £ 8-451-433-11 DEFLECTION YOKE (Y28GICM)
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
£ 8-451-485-11 DEFLECTION YOKE (Y32C2C2-M)
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
66 1-452-724-11 COIL, NA ROTATION (RT-165)
67 £ 8-453-005-31 NECK ASSY, NA297-M3
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
£ 8-453-011-11 NECK ASSY, NA299-M
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
68 *A-1644-084-A VM BOARD, COMPLETE
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
*A-1644-089-A VM BOARD, COMPLETE
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
69 *A-1638-092-A C BOARD, COMPLETE
70 4-369-318-31 SPRING, TENSION
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
4-200-433-01 SPRING, EXTENSION
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
71 *4-203-390-01 CUSHION, DGC
72 £ 1-411-893-11 COIL, DEMAGNETIC
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
£ 1-416-450-11 COIL, DEMAGNETIC
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
73 4-203-769-01 DGC HOLDER (28”)
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
4-045-294-01 HOLDER, DGC
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
74 3-704-495-01 SPACER, DY
75 4-200-693-01 HOLDER, HV CABLE
(KV-28WF3A/28WF3B/28WF3D/28WF3E/28WF3K)
4-203-022-01 HOLDER, HV CABLE
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
76 £ 1-251-317-31 CAP, ASSY HIGH VOLTAGE
77 4-203-216-01 PT-SCREW
(KV-32WF3A/32WF3B/32WF3D/32WF3E/32WF3K)
78 4-308-870-00 CLIP, LEAD WIRE
79 1-425-032-00 MAGNET, DISK; 10MM Ø
80 1-452-094-00 MAGNET, ROTATABLE DISK; 15MM Ø
81 X-4387-214-1 PERMALLOY ASSY, CORRECTION
82 3-701-007-00 BAND BINDING
