97
KV-28WF3/32WF3
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R1821 1-216-023-00 RES,CHIP 82 5% 1/10W
R1822 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1831 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1832 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1833 1-216-295-91 SHORT 0
R1835 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1844 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1845 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1846 1-216-077-00 RES,CHIP 15K 5% 1/10W
R1848 1-216-025-91 RES,CHIP 100 5% 1/10W
R1849 1-216-001-00 RES,CHIP 10 5% 1/10W
R1850 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1851 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1852 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1853 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1854 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1855 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1856 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1857 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1858 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1859 1-216-017-91 RES,CHIP 47 5% 1/10W
R1861 1-216-295-91 SHORT 0
R1864 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R1866 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1867 1-216-075-00 RES,CHIP 12K 5% 1/10W
R1868 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1869 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1871 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1878 1-216-009-00 RES,CHIP 22 5% 1/10W
R1879 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1880 1-216-085-00 RES,CHIP 33K 5% 1/10W
R1881 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1882 1-216-085-00 RES,CHIP 33K 5% 1/10W
R1885 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1886 1-216-295-91 SHORT 0
R1888 1-216-021-00 RES,CHIP 68 5% 1/10W
R1890 1-216-295-91 SHORT 0
R1893 1-216-295-91 SHORT 0
R1894 1-216-047-91 RES,CHIP 820 5% 1/10W
R1895 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R1896 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1897 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1901 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1902 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1903 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1904 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1905 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1906 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1907 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1908 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1909 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1910 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1911 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1912 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1922 1-216-025-91 RES,CHIP 100 5% 1/10W
R1928 1-216-115-00 RES,CHIP 560K 5% 1/10W
R1934 1-216-115-00 RES,CHIP 560K 5% 1/10W
R1940 1-216-025-91 RES,CHIP 100 5% 1/10W
< CRYSTAL >
X401 1-767-639-21 VIBRATOR, CRYSTAL
X1801 1-579-175-11 VIBRATOR, CERAMIC
**********************************************************************
*A-1632-777-A A BOARD COMPLETE (KV-28WF3A)
****************
*A-1632-776-A A BOARD COMPLETE (KV-28WF3B)
****************
*A-1632-724-A A BOARD COMPLETE (KV-28WF3D)
****************
*A-1632-778-A A BOARD COMPLETE (KV-28WF3E)
****************
*A-1632-779-A A BOARD COMPLETE (KV-28WF3K)
****************
*A-1632-772-A A BOARD COMPLETE (KV-32WF3A)
****************
*A-1632-773-A A BOARD COMPLETE (KV-32WF3B)
****************
*A-1632-724-A A BOARD COMPLETE (KV-32WF3D)
****************
*A-1632-774-A A BOARD COMPLETE (KV-32WF3E)
****************
*A-1632-775-A A BOARD COMPLETE (KV-32WF3K)
****************
< CAPACITOR >
C101 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C102 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C103 1-163-253-11 CERAMIC CHIP 120PF 5% 50V
(KV-28WF3B/32WF3B)
C105 1-126-965-11 ELECT 22MF 20% 50V
C111 1-126-964-11 ELECT 10MF 20% 50V
C112 1-164-346-11 CERAMIC CHIP 1MF 16V
C114 1-164-346-11 CERAMIC CHIP 1MF 16V
C116 1-126-967-11 ELECT 47MF 20% 16V
C117 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C118 1-126-967-11 ELECT 47MF 20% 16V
C119 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C120 1-126-964-11 ELECT 10MF 20% 50V
C121 1-164-299-11 CERAMIC CHIP 0.22MF 10% 25V
C122 1-164-346-11 CERAMIC CHIP 1MF 16V
C126 1-126-967-11 ELECT 47MF 20% 16V
C127 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C128 1-126-967-11 ELECT 47MF 20% 16V
C129 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C130 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C131 1-164-346-11 CERAMIC CHIP 1MF 16V
C132 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C133 1-164-346-11 CERAMIC CHIP 1MF 16V
C134 1-126-964-11 ELECT 10MF 20% 50V
C135 1-164-299-11 CERAMIC CHIP 0.22MF 10% 25V
C136 1-126-964-11 ELECT 10MF 20% 50V
C137 1-164-506-11 CERAMIC CHIP 4.7MF 16V
C140 1-164-506-11 CERAMIC CHIP 4.7MF 16V
C141 1-164-506-11 CERAMIC CHIP 4.7MF 16V
C143 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
(KV-28WF3B/32WF3B)
AB
