100
KV-28WF3/32WF3
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
< IC >
IC101 8-752-068-45 IC CXA1855Q
IC102 8-759-267-25 IC LM2940T-9.0
IC104 8-759-514-57 IC BA7046F
IC201 8-759-437-97 IC MSP3400C-PS-C6-T-S (KV-28WF3A/28WF3D/
KV-32WF3A/32WF3D)
8-759-491-94 IC MSP3410D-PS-B4-T
(KV-28WF3B/28WF3E/28WF3K/
KV-32WF3B/32WF3E/32WF3K)
IC302 8-759-447-68 IC TDA9143/N1
IC303 8-759-288-85 IC TDA4665T-T
IC304 8-759-439-60 IC TDA9170T
IC1001 8-759-442-44 IC SDA30C164-2-GEG
IC1002 8-759-444-65 IC M27C4001-15C1-AE408
1-750-797-11 SOCKET, PLCC (IC1002)
IC1003 8-759-378-21 IC ST24C16FB6
IC1004 8-759-259-18 IC MB3793-42PNF
IC1006 8-759-988-13 IC LM393PS
IC1101 8-752-383-01 IC CXD2053AS
IC1303 8-759-385-76 IC MC14052BDR2
(KV-28WF3A/28WF3D/28WF3E/28WF3K/
KV-32WF3A/32WF3D/32WF3E/32WF3K)
IC2001 8-759-438-62 IC SDA5275
IC2004 8-759-483-52 IC HYB514400BJ-60
< COIL >
L101 1-412-751-11 INDUCTOR 18UH (KV-28WF3B/32WF3B)
L321 1-412-006-31 INDUCTOR CHIP 10UH
< TRANSISTOR >
Q102 8-729-620-06 TRANSISTOR 2SC3052-EF
Q103 8-729-039-67 TRANSISTOR BSS83 (KV-28WF3B/32WF3B)
Q104 8-729-620-06 TRANSISTOR 2SC3052-EF (KV-28WF3B/32WF3B)
Q106 8-729-216-22 TRANSISTOR 2SA1162-G (KV-28WF3B/32WF3B)
Q107 8-729-216-22 TRANSISTOR 2SA1162-G
Q108 8-729-620-06 TRANSISTOR 2SC3052-EF
Q109 8-729-216-22 TRANSISTOR 2SA1162-G
Q110 8-729-038-96 TRANSISTOR IMZ1A-T109
Q112 8-729-216-22 TRANSISTOR 2SA1162-G
Q113 8-729-216-22 TRANSISTOR 2SA1162-G
Q120 8-729-901-00 TRANSISTOR DTC124EK
Q200 8-729-620-06 TRANSISTOR 2SC3052-EF
Q205 8-729-620-06 TRANSISTOR 2SC3052-EF
Q301 8-729-620-06 TRANSISTOR 2SC3052-EF
Q302 8-729-620-06 TRANSISTOR 2SC3052-EF
Q315 8-729-038-96 TRANSISTOR IMZ1A-T109
Q316 8-729-038-96 TRANSISTOR IMZ1A-T109
Q317 8-729-038-96 TRANSISTOR IMZ1A-T109
Q321 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
(KV-28WF3A/28WF3D/28WF3E/28WF3K/
KV-32WF3A/32WF3D/32WF3E/32WF3K)
Q322 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
(KV-28WF3A/28WF3D/28WF3E/28WF3K/
KV-32WF3A/32WF3D/32WF3E/32WF3K)
Q1001 8-729-620-06 TRANSISTOR 2SC3052-EF (KV-28WF3B/32WF3B)
Q1015 8-729-900-53 TRANSISTOR DTC114EK
Q1101 8-729-620-06 TRANSISTOR 2SC3052-EF
Q1301 8-729-216-22 TRANSISTOR 2SA1162-G
Q1302 8-729-216-22 TRANSISTOR 2SA1162-G
Q1303 8-729-216-22 TRANSISTOR 2SA1162-G
Q1304 8-729-216-22 TRANSISTOR 2SA1162-G
Q1305 8-729-216-22 TRANSISTOR 2SA1162-G
Q1306 8-729-216-22 TRANSISTOR 2SA1162-G
Q1311 8-729-620-06 TRANSISTOR 2SC3052-EF
Q1312 8-729-620-06 TRANSISTOR 2SC3052-EF
Q1313 8-729-216-22 TRANSISTOR 2SA1162-G
Q2005 8-729-620-06 TRANSISTOR 2SC3052-EF
Q2006 1-801-806-11 TRANSISTOR DTC144EKA
Q2007 1-801-806-11 TRANSISTOR DTC144EKA
< RESISTOR >
JR201 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
JR202 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
JR1001 1-216-295-91 SHORT 0
JR1002 1-216-295-91 SHORT 0
JR1003 1-216-295-91 SHORT 0
JR1004 1-216-295-91 SHORT 0
JR1008 1-216-025-91 RES,CHIP 100 5% 1/10W
JR1009 1-216-025-91 RES,CHIP 100 5% 1/10W
JR1010 1-216-025-91 RES,CHIP 100 5% 1/10W
JR1011 1-216-025-91 RES,CHIP 100 5% 1/10W
JR1301 1-216-295-91 SHORT 0 (KV-28WF3B/32WF3B)
JR1302 1-216-295-91 SHORT 0 (KV-28WF3B/32WF3B)
JR1405 1-216-295-91 SHORT 0
R101 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R102 1-216-025-91 RES,CHIP 100 5% 1/10W
R103 1-216-025-91 RES,CHIP 100 5% 1/10W
R104 1-216-073-00 RES,CHIP 10K 5% 1/10W
R106 1-216-033-00 RES,CHIP 220 5% 1/10W
R107 1-216-295-91 SHORT 0
(KV-28WF3A/28WF3D/28WF3E/28WF3K/
KV-32WF3A/32WF3D/32WF3E/32WF3K)
R108 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R109 1-216-085-00 RES,CHIP 33K 5% 1/10W
R110 1-216-097-91 RES,CHIP 100K 5% 1/10W
R111 1-216-041-00 RES,CHIP 470 5% 1/10W
R112 1-216-041-00 RES,CHIP 470 5% 1/10W
R113 1-216-041-00 RES,CHIP 470 5% 1/10W
R114 1-216-311-00 RES,CHIP 6.8 5% 1/10W
R115 1-216-311-00 RES,CHIP 6.8 5% 1/10W
R116 1-216-311-00 RES,CHIP 6.8 5% 1/10W
R117 1-216-022-00 RES,CHIP 75 5% 1/10W
R118 1-216-022-00 RES,CHIP 75 5% 1/10W
R119 1-216-022-00 RES,CHIP 75 5% 1/10W
R120 1-216-022-00 RES,CHIP 75 5% 1/10W
R121 1-216-022-00 RES,CHIP 75 5% 1/10W
R122 1-216-073-00 RES,CHIP 10K 5% 1/10W
R123 1-216-073-00 RES,CHIP 10K 5% 1/10W
R124 1-216-113-00 RES,CHIP 470K 5% 1/10W
R126 1-216-039-00 RES,CHIP 390 5% 1/10W
R127 1-216-039-00 RES,CHIP 390 5% 1/10W
R128 1-216-113-00 RES,CHIP 470K 5% 1/10W
R129 1-216-643-11 METAL CHIP 470 0.50% 1/10W
(KV-28WF3B/32WF3B)
