KV-25C5/29C5 The components identified by
shading and marked A\ are critical
. for safety
Replace only with the part number
specified.
REFNO. —-PART.NO DESCRIPTION REMARK REFNO. — PART.NO DESCRIPTION REMARK
1537 1-406-214-11 COIL, HORIZONTAL LINEARITY W220 8-719-109-89 DIODE RD5.6ESB2
(KV-25C5A/25C5B/25C5D/25C5E/25C5K/25C5R)
1-409-855-11 COIL, HORIZONTAL LINEARITY R001 1-216-025-00 RES, CHIP 100 5% =1/10W
(KV-29C5A/29C5B/29C5D/29C5E/29C5K/29C5R) R002 1-216-025-00 RES,CHIP 100 5% 1/100
1540 1-535-465-11 LEAD JUMPER (5.0MM) R003 1-216-065-00 RES, CHIP 4.7K 5% 1/108
; R004 1-216-065-00 RES,CHIP 4.7K 5% = 1/100
L571 1-412-533-21 INDUCTOR 470H R005 1-216-065-00 RES ,CHIP 4.7K 5% = 1/100
1602 1-408-417-00 INDUCTOR 47UH
R007 1-216-065-00 RES, CHIP 4.1K 5% 1/100
< PHOTO COUPLER > R009 1-216-025-00 RES, CHIP 100 58 = 1/10W
R010 1-216-025-00 RES, CHIP 100 58 = 1/10W
PROOL A 8-749-010-64 PHOTO COUPLER PCL23F2 0 R011 1-216-025-00 RES, CHIP 100 5% = 1/10W
. peal . —- ae R012 1-247-807-31 CARBON 100 «5% = (1 /4W
< TRANSISTOR >
R013 1-216-214-00 RES, CHIP 4.7K 5% = 1/88
Q004 8-729-216-22 TRANSISTOR 2SA1162-G R014 1-216-057-00 RES, CHIP 2.2K 5% = 1/10W
9005 1-801-806-11 TRANSISTOR DTC144EKA R015 1-216-049-00 RES ,CHIP 1K 5%) 1 /10W
Q006 1-801-806-11 TRANSISTOR DIC144EKA R016 1-216-073-00 RES, CHIP 10K 5% = 1 /10W
Q007 8-729-620-06 TRANSISTOR 2SC3052-EF R019 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
Q008 8-729-620-06 TRANSISTOR 2SC3052-EF
R023 1-216-295-00 SHORT 0
Q009 8-729-620-06 TRANSISTOR 2SC3052-EF R029 1-216-073-00 RES,CHIP 10K 05% = 1/10W
Q010 8-729-620-06 TRANSISTOR 2SC3052-EF R030 1-216-081-00 RES,CHIP 22K 5%) 1 /10W
Q011 1-801-806-11 TRANSISTOR DTCL44EK (KV-29C5A/29C5B/29C5D/29C5E/29C5K/29C5R)
Q012 8-729-620-06 TRANSISTOR 2SC3052-EF R032 1-216-089-00 RES,CHIP 4m 53 = 1/108
013 8~729-620-06 TRANSISTOR 2SC3052-EF
(KV-29C5A/29C5B/29C5D/29C5E/29C5K/29C5R) R034 1-216-065-00 RES, CHIP 4.7K 5% = 1/108
R035 1-216-049-00 RES, CHIP 1K 581/104
Q014 8-729-120-28 TRANSISTOR 2SC1623-L5L6 R036 1-216-065-00 RES, CHIP 4.7K 53 = 1/100
101 8-729-216-22 TRANSISTOR 2SA1162-G R038 1-216-073-00 RES,CHIP 10K 53) 1/10
107 8-729-022-54 TRANSISTOR 28C3779C,D-AA (KV-25C5B/29C5B) R039 1-216-089-00 RES,CHIP AK 5% 1/100
Q109 1-801-806-11 TRANSISTOR DTC144EKA (KV-25C5B/29C5B)
Q110 1~801-806-11 TRANSISTOR DTC144EKA (KV-25C5B/29C5B) R050 1-216-041-00 RES, CHIP 470 5% /10W
R051 1-216-049-00 RES, CHIP 1K 581/100
gill 8-729-216-22 TRANSISTOR 2SA1162-G (KV-25C5B/29C5B) R053 1-216-065-00 RES, CHIP 4.7K 53 = 1/108
112 1-801-806-11 TRANSISTOR DIC144EKA (KV-25C5B/29C5B) R054 1-216-041-00 RES, CHIP 470 581/100
202 8-729-620-06 TRANSISTOR 2SC3052-EF R055 1-216-081-00 RES,CHIP 22K 581/109
401 8-729-216-22 TRANSISTOR 2SA1162-G
9405 8-729-120-28 TRANSISTOR 2SC1623-L5L6 R056 1-216-105-00 RES,CHIP 220K 5% = 1/109
R057 1-216-075-00 RES,CHIP 12K 53) = 1/10¥
9408 8~729-120-28 TRANSISTOR 28C1623-L5L6 R058 1-216-063-91 RES, CHIP 3.9K 53 1/109
501 8~729-620-06 TRANSISTOR 2SC3052-EF R059 1-216-089-00 RES,CHIP 47K 581 /10¥
9532 8-729-038-83 TRANSISTOR 2SK2251-01-F19 R060 1-216-174-00 RES, CHIP 100 53 = -1/8W
533 8~729-040-62 TRANSISTOR 2$D2539(LBSONY)
9535 8~729-119-80 TRANSISTOR 2SC2688-LK R061 1-216-174-00 RES ,CHIP 100 5% = -1/8W
R062 1-216-033-00 RES,CHIP 220. 58 «1/108
9571 8-729-105-08 TRANSISTOR 2SA1330-06 R063 1-216-065-00 RES,CHIP 4.7K 53 = 1/107
Q574 8~729-120-28 TRANSISTOR 28C1623-L5L6 (KY -25C5B/29C5B)
575 1~801-806-11 TRANSISTOR DICL44EKA R064 1-216-065-00 RES,CHIP 4.7% 53 = 1/107
576 8~729-120-28 TRANSISTOR 2SC1623-L5L6 (KY -25C5B/29C5B)
601 8-729-216-22 TRANSISTOR 2SA1162-6
R065 1-216-025-00 RES,CHIP 100 5% = 1/107
< RESISTOR > R066 1-216-065-00 RES, CHIP 4.7K 5% = 1/107
R067 1-216-065-00 RES, CRIP 4.7K 5% = 1/10¥
URO12 = 1~216-295-00 SHORT 0 (RV-25C5A/25C5D/25C5E/25C5K/ R069 1-216-049-00 RES, CHIP 1K 5S 1/10¥
25C5R/29C5A/29C5D/29C5E/ R070 1-216-081-00 RES, CHIP 22K 5% = 1/10¥
29C5K/29C5R)
JR023 1~216-296-00 SHORT 0 RO71 1-216-214-00 RES, CHIP 4.7K 5% 1/88
JRO31 1~216-295-00 SHORT 0 R072 1-216-097-00 RES, CHIP 100K 5% 1/107
R073 1-216-097-00 RES, CHIP 100K 58 = 1/107
JR033. «= 1~216-296-00 SHORT 0 RO75 1-216-069-00 RES, CHIP 6.8K 53 1/107
JR403 1~216-073-00 RES, CHIP 10K 5% = 1/10W R077 1-216-083-00 RES,CHIP 27K «5% /10¥
JRA09 =: 1~216-295-00 SHORT 0
JRA1L =: 1~216-295-00 SHORT 0 R078 1-216-065-00 RES, CHIP 4.7K 5% 1/107
JRr412 1~216-295-00 SHORT 0 (KV-29C5A/29C5B/29C5D/29C51 /29C5K/29C5R)
R080 1-216-073-00 RES,CHIP 10K 5301/10
JR610 «= 1~216-296-00 SHORT 0 R081 1-216-073-00 RES, CRIP 10K 581/101
JR613 1~216-296-00 SHORT 0
62
