— 44 —
KV-29FS13 / 29FS13C
NOTE: The components identifi ed by shading and
!
mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
C543 1-136-169-00 FILM 0.22µF 5% 50V
!
C546 1-126-965-11 ELECT 22µF 20% 50V
!
C547 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C548 1-104-710-11 ELECT 22µF 160V
C549 1-126-934-11 ELECT 220µF 20% 16V
C550 1-107-846-11 FILM 0.1µF 5% 250V
!
C551 1-137-417-11 MYLAR 0.0047µF 10% 200V
C553 1-107-662-11 ELECT 22µF 20% 250V
C554 1-102-110-00 CERAMIC 220pF 10% 50V
!
C555 1-117-629-11 FILM 2700pF 3% 1.2KV
C601 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C602 1-126-967-11 ELECT 47µF 20% 50V
C604 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
!
C606 1-113-920-11 CERAMIC 2200 PF 20% 250V
!
C607 1-136-311-11 MYLAR 0.47µF 20% 125V
(KV-29FS13 ONLY)
C609 1-126-968-11 ELECT 100µF 20% 50V
C610 1-126-964-11 ELECT 10µF 20% 50V
!
C611 1-113-920-11 CERAMIC 2200 PF 20% 250V
!
C612 1-128-718-11 ELECT 560µF 20% 400V
(KV-29FS13C ONLY)
C612 1-128-717-11 ELECT 680µF 20% 250V
(KV-29FS13 ONLY)
C613 1-126-964-11 ELECT 10µF 20% 50V
C614 1-130-495-00 MYLAR 0.1µF 5% 50V
C615 1-130-202-00 FILM 0.022µF 10% 400V
(KV-29FS13C ONLY)
C616 1-107-824-11 CERAMIC 220pF 5% 1KV
(KV-29FS13C ONLY)
C617 1-125-893-11 FILM 680pF 3% 1.5KV
C618 1-164-081-11 CERAMIC 470pF 10% 50V
C619 1-136-356-11 MYLAR 470pF 5% 50V
C620 1-104-665-11 ELECT 100µF 20% 25V
C621 1-125-772-91 CERAMIC 1500pF 10% 2KV
C622 1-164-625-11 CERAMIC 680pF 10% 500V
C623 1-164-625-11 CERAMIC 680pF 10% 500V
C624 1-131-867-51 ELECT 100µF 160V
C625 1-135-573-51 ELECT 15000µF 20% 25V
(KV-29FS13C ONLY)
C625 1-135-412-51 ELECT 1000UF 20% 25V
(KV-29FS13 ONLY)
C626 1-135-573-51 ELECT 15000µF 20% 25V
C627 1-136-189-00 MYLAR 0.1µF 10% 250V
C628 1-104-665-11 ELECT 100µF 20% 25V
C634 1-137-605-11 MYLAR 0.01µF 10% 250V
C635 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C636 1-126-970-11 ELECT 330µF 20% 50V
C637 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C638 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C639 1-126-965-11 ELECT 22µF 20% 50V
C641 1-107-679-91 ELECT 10µF 20% 450V
C643 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C647 1-161-964-91 CERAMIC 0.0047µF 250V
C648 1-136-346-21 MYLAR 0.22µF 20% 300V
C652 1-130-471-00 MYLAR 0.001µF 5% 50V
C654 1-107-636-11 ELECT 10µF 20% 160V
!
C655 1-136-311-11 MYLAR 0.47µF 20% 300V
C657 1-104-664-11 ELECT 47µF 20% 25V
C658 1-135-573-51 ELECT 15000µF 20% 25V
(KV-29FS13C ONLY)
C658 1-135-412-51 ELECT 1000UF 20% 25V
(KV-29FS13 ONLY)
C659 1-135-573-51 ELECT 15000µF 20% 25V
C2001 1-104-664-11 ELECT 47µF 20% 25V
CONNECTOR
* CN301 1-564-507-11 PLUG, CONNECTOR 4P
* CN406 1-564-507-11 PLUG, CONNECTOR 4P
CN460 1-573-298-21 CONNECTOR, BOARD TO BOARD 20P
* CN501 1-580-798-11 CONNECTOR PIN (DY) 6P
CN502 1-564-509-11 PLUG, CONNECTOR 6P
* CN504 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
* CN506 1-564-508-11 PLUG, CONNECTOR 5P
* CN515 1-564-510-11 PLUG, CONNECTOR 7P
CN602 1-580-843-11 PIN, CONNECTOR (POWER)
* CN603 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
* CN2001 1-564-511-11 PLUG, CONNECTOR 8P
* CN2003 1-564-506-11 PLUG, CONNECTOR 3P
* CN2005 1-764-333-11 PLUG, CONNECTOR 10P
* CN2006 1-764-333-11 PLUG, CONNECTOR 10P
* CN2007 1-564-512-11 PLUG, CONNECTOR 9P
* CN2008 1-564-512-11 PLUG, CONNECTOR 9P
DIODE
D201 8-719-108-12 DIODE RD9.1EW-T1
D202 8-719-108-12 DIODE RD9.1EW-T1
(KV-29FS13C ONLY)
D203 8-719-108-12 DIODE RD9.1EW-T1
D204 8-719-982-22 DIODE MTZJ-T-77-30D
D205 8-719-108-12 DIODE RD9.1EW-T1
D206 8-719-108-12 DIODE RD9.1EW-T1
D208 8-719-108-12 DIODE RD9.1EW-T1
D209 8-719-069-60 DIODE UDZSTE-179.1B
D210 8-719-110-17 DIODE MTZJ-T-77-10B
D211 8-719-108-12 DIODE RD9.1EW-T1
D212 8-719-110-17 DIODE MTZJ-T-77-10B
D213 8-719-110-17 DIODE MTZJ-T-77-10B
A
To Next Page
