— 45 —
KV-29FS13 / 29FS13C
NOTE: The components identifi ed by shading and
!
mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
D214 8-719-108-12 DIODE RD9.1EW-T1
D215 8-719-108-12 DIODE RD9.1EW-T1
D230 8-719-108-12 DIODE RD9.1EW-T1
D231 8-719-108-12 DIODE RD9.1EW-T1
D232 8-719-108-12 DIODE RD9.1EW-T1
D233 8-719-108-12 DIODE RD9.1EW-T1
D401 8-719-110-17 DIODE MTZJ-T-77-10B
!
D501 8-719-945-80 DIODE ERC06-15S
D502 8-719-908-03 DIODE GP08DPKG23
D503 8-719-908-03 DIODE GP08DPKG23
!
D504 8-719-945-80 DIODE ERC06-15S
D505 8-719-312-10 DIODE RU4AM-T3
D506 8-719-302-43 DIODE RGP10GPKG3
D507 8-719-991-33 DIODE 1SS133T-77
D508 8-719-991-33 DIODE 1SS133T-77
D509 8-719-109-89 DIODE MTZJ-T-77-5.6C
D510 8-719-908-03 DIODE GP08DPKG23
D511 8-719-302-43 DIODE RGP10GPKG23
D512 8-719-073-01 DIODE MA111-TX
D513 8-719-979-85 DIODE RGP15GPKG23
D514 8-719-979-85 DIODE RGP15GPKG23
D515 8-719-073-01 DIODE MA111-TX
!
D516 8-719-991-33 DIODE 1SS133T-77
!
D517 8-719-991-33 DIODE 1SS133T-77
!
D518 8-719-921-63 DIODE MTZJ-T-77-7.5X
!
D519 8-719-979-84 DIODE EGP20DPKG23
!
D520 8-719-073-01 DIODE MA111-TX
D521 8-719-991-33 DIODE 1SS133T-77
D522 8-719-073-01 DIODE MA111-TX
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
D603 8-719-982-26 DIODE MTZJ-T-77-33B
D604 8-719-028-72 DIODE RGP02-17PKG23
!
D605 8-719-510-53 DIODE D4SB60L-F
!
D606 8-719-108-18 DIODE TF541M
D607 8-719-991-33 DIODE 1SS133T-77
D608 8-719-110-53 DIODE MTZJ-T-77-20B
D609 8-719-311-31 DIODE RU-1P
(KV-29FS13C ONLY)
D610 8-719-210-21 DIODE 11EQS04-NTA1B
D611 8-719-046-74 DIODE 10ELS2N-TA1B2
D612 8-719-110-17 DIODE MTZJ-T-77-10B
D613 8-719-046-74 DIODE 10ELS2N-TA1B2
D614 8-719-046-74 DIODE 10ELS2N-TA1B2
D615 8-719-312-10 DIODE RU4AM-T3
D616 8-719-510-37 DIODE D5LC20U
D617 8-719-110-31 DIODE MTZJ-T-77-12C
D618 8-719-991-33 DIODE 1SS133T-77
D619 8-719-110-17 DIODE MTZJ-T-77-10B
D620 8-719-510-37 DIODE D5LC20U
D622 8-719-077-76 DIODE D2SB60A-F04
D623 8-719-081-70 DIODE BA159DGPPKG3
D624 8-719-991-33 DIODE 1SS133T-77
D625 8-719-991-33 DIODE 1SS133T-77
D626 8-719-046-74 DIODE 10ELS2N-TA1B2
D627 8-719-110-03 DIODE MTZJ-T-77-7.5A
D628 8-719-510-48 DIODE D1N20R-TA
D2001 8-719-070-80 DIODE LNK0120022G
D2002 8-719-110-17 DIODE MTZJ-T-77-10B
D2003 8-719-108-12 DIODE RD9.1EW-T1
D2004 8-719-921-44 DIODE MTZJ-T-77-5.1C
D2005 8-719-921-44 DIODE MTZJ-T-77-5.1C
FUSE
!
F601 1-532-506-51 FUSE 6.3A/250V
(KV-29FS13C ONLY)
!
F601 1-576-193-11 FUSE 6.3A/125V
(KV-29FS13 ONLY)
FERRITE BEAD
FB501 1-410-397-21 FERRITE 1.1µH
FB502 1-410-397-21 FERRITE 1.1µH
FB503 1-410-397-21 FERRITE 1.1µH
FB600 1-412-911-11 FERRITE 0µH
FB601 1-412-911-11 FERRITE 0µH
FB602 1-412-911-11 FERRITE 0µH
FB603 1-412-911-11 FERRITE 0µH
FB604 1-412-911-11 FERRITE 0µH
FB605 1-412-911-11 FERRITE 0µH
FB606 1-412-911-11 FERRITE 0µH
FB609 1-412-911-11 FERRITE 0µH
FB610 1-412-911-11 FERRITE 0µH
IC
!
IC402 8-759-573-40 IC TDA8580Q/N1
!
IC501 8-759-700-07 IC NJM2903M-TE2
IC502 8-759-980-58 IC TDA8172
!
IC601 8-749-018-44 IC STR-F6456
(KV-29FS13C ONLY)
!
IC601 8-749-018-43 IC STR-F6426
(KV-29FS13 ONLY)
!
IC602 8-749-016-47 IC EA135-F12
IC603 8-759-653-07 IC PQ09RD21
IC604 8-759-714-26 IC LM7805CT
IC2001 8-742-212-20 HYB IC SBX3081-71
A
