— 46 —
KV-29FS13 / 29FS13C
NOTE: The components identifi ed by shading and
!
mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
JACK
J201 1-794-119-11 TERMINAL BLOCK, S 4P
J202 1-794-267-11 JACK, PIN 3P
J203 1-794-118-11 JACK BLOCK, PIN 3P
J205 1-794-116-11 JACK BLOCK, PIN 2P
J206 1-794-117-11 JACK BLOCK, PIN 3P
J402 1-794-116-11 JACK BLOCK, PIN 2P
CHIP CONDUCTOR
JR001 1-216-295-11 SHORT
JR002 1-216-295-11 SHORT
JR402 1-216-295-11 SHORT
JR403 1-216-295-11 SHORT
JR404 1-216-295-91 SHORT
JR405 1-216-295-11 SHORT
JR410 1-216-295-91 SHORT
JR411 1-216-295-11 SHORT
JR471 1-164-222-11 CERAMIC CHIP 0.22µF 25V
JR472 1-216-295-11 SHORT
JR501 1-216-295-11 SHORT
JR502 1-216-295-11 SHORT
JR503 1-216-295-11 SHORT
JR505 1-216-295-11 SHORT
JR522 1-216-295-11 SHORT
JR523 1-216-295-11 SHORT
JR526 1-216-295-11 SHORT
JR527 1-216-295-11 SHORT
JR2003 1-216-295-11 SHORT
COIL
L101 1-412-029-11 INDUCTOR 10µH
L102 1-412-032-11 INDUCTOR 100µH
L103 1-412-029-11 INDUCTOR 10µH
L501 1-409-955-11 INDUCTOR 8MH
L502 1-412-552-11 INDUCTOR 2.2MH
L503 1-406-677-11 INDUCTOR 10MH
L504 1-412-533-21 INDUCTOR 47µH
L505 1-406-978-11 INDUCTOR 150µH
L506 1-406-677-11 INDUCTOR 10MH
L507 1-412-552-11 INDUCTOR 2.2MH
!
L510 1-412-528-11 INDUCTOR 18µH
L603 1-412-529-11 INDUCTOR 22µH
L604 1-412-525-31 INDUCTOR 10µH
L605 1-412-529-11 INDUCTOR 22µH
PHOTO COUPLER
!
PH601 8-749-010-64 PHOTO COUPLER PC123FY2
IC LINK
!
PS401 1-532-686-21 LINK, IC 2.7A/150V
TRANSISTOR
Q101 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q410 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q411 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q501 8-729-140-50 TRANSISTOR 2SC3209LK-TP
!
Q502 8-729-046-07 TRANSISTOR 2SD2578-YB
!
Q503 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
!
Q504 8-729-053-87 TRANSISTOR KTC4370A
!
Q505 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
!
Q506 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
!
Q507 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q601 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q602 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
!
Q603 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q604 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
!
Q605 8-729-046-40 TRANSISTOR 2SK2663
Q606 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q607 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q608 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q609 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R105 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R107 1-216-025-11 RES-CHIP 100 5% 1/10W
R108 1-216-025-11 RES-CHIP 100 5% 1/10W
R115 1-216-295-11 SHORT
R201 1-216-113-00 RES-CHIP 470K 5% 1/10W
R202 1-216-113-00 RES-CHIP 470K 5% 1/10W
R203 1-216-022-00 RES-CHIP 75 5% 1/10W
R204 1-216-081-00 RES-CHIP 22K 5% 1/10W
R205 1-216-085-00 RES-CHIP 33K 5% 1/10W
R208 1-215-924-00 METAL OXIDE 15K 5% 3W
R210 1-216-022-00 RES-CHIP 75 5% 1/10W
R214 1-216-113-00 RES-CHIP 470K 5% 1/10W
R215 1-216-113-00 RES-CHIP 470K 5% 1/10W
R235 1-216-113-00 RES-CHIP 470K 5% 1/10W
R237 1-216-033-00 RES-CHIP 220 5% 1/10W
R238 1-216-033-00 RES-CHIP 220 5% 1/10W
R239 1-216-113-00 RES-CHIP 470K 5% 1/10W
R401 1-216-080-00 RES-CHIP 20K 5% 1/10W
R402 1-216-073-00 RES-CHIP 10K 5% 1/10W
R411 1-249-417-11 CARBON 1K 5% 1/4W
R412 1-216-113-00 RES-CHIP 470K 5% 1/10W
R413 1-216-113-00 RES-CHIP 470K 5% 1/10W
R414 1-249-417-11 CARBON 1K 5% 1/4W
