— 47 —
KV-29FS13 / 29FS13C
NOTE: The components identifi ed by shading and
!
mark are critical for safety. Replace only with
part number specifi ed.
A component identifi ed by this
X
symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
R421 1-249-425-11 CARBON 4.7K 5% 1/4W
R422 1-249-389-11 CARBON 4.7 5% 1/4W
R426 1-216-009-91 RES-CHIP 22 5% 1/10W
R429 1-216-113-00 RES-CHIP 470K 5% 1/10W
R430 1-216-049-11 RES-CHIP 1K 5% 1/10W
R431 1-216-049-11 RES-CHIP 1K 5% 1/10W
R433 1-216-113-00 RES-CHIP 470K 5% 1/10W
R436 1-216-073-00 RES-CHIP 10K 5% 1/10W
(KV-29FS13C ONLY)
R436 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
(KV-29FS13 ONLY)
R437 1-216-073-00 RES-CHIP 10K 5% 1/10W
(KV-29FS13C ONLY)
R437 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
(KV-29FS13 ONLY)
R438 1-216-073-00 RES-CHIP 10K 5% 1/10W
(KV-29FS13C ONLY)
R438 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
(KV-29FS13 ONLY)
R440 1-216-097-11 RES-CHIP 100K 5% 1/10W
R441 1-216-081-00 RES-CHIP 22K 5% 1/10W
R442 1-216-025-11 RES-CHIP 100 5% 1/10W
R445 1-216-073-00 RES-CHIP 10K 5% 1/10W
R446 1-215-457-00 METAL 33K 1% 1/4W
R447 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R454 1-216-025-11 RES-CHIP 100 5% 1/10W
R490 1-216-073-00 RES-CHIP 10K 5% 1/10W
R501 1-249-425-11 CARBON 4.7K 5% 1/4W
!
R502 1-216-455-21 METAL OXIDE 560 5% 2W
!
R503 1-249-425-11 CARBON 4.7K 5% 1/4W
R505 1-249-401-11 CARBON 47 5% 1/4W
!
R506 1-215-883-11 METAL OXIDE 33 5% 2W
!
R507 1-260-328-11 CARBON 1K 5% 1/2W
R508 1-249-433-11 CARBON 22K 5% 1/4W
!
R509 1-215-891-11 METAL OXIDE 680 5% 2W
R510 1-249-411-11 CARBON 330 5% 1/4W
R511 1-249-377-11 CARBON 0.47 5% 1/4W
R512 1-215-910-00 METAL OXIDE 68 5% 3W
!
R513 1-215-907-11 METAL OXIDE 22 5% 3W
R514 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R516 1-249-425-11 CARBON 4.7K 5% 1/4W
R517 1-215-445-00 METAL 10K 1% 1/4W
R518 1-249-427-11 CARBON 6.8K 5% 1/4W
R519 1-249-427-11 CARBON 6.8K 5% 1/4W
!
R520 1-215-884-11 METAL OXIDE 47 5% 2W
!
R521 1-249-413-11 CARBON 470 5% 1/4W
R522 1-249-417-11 CARBON 1K 5% 1/4W
R523 1-216-073-00 RES-CHIP 10K 5% 1/10W
R524 1-249-429-11 CARBON 10K 5% 1/4W
!
R525 1-208-804-11 METAL CHIP 8.2K 0.50% 1/10W
R526 1-208-814-91 METAL CHIP 22K 0.50% 1/10W
R528 1-215-429-00 METAL 2.2K 1% 1/4W
R529 1-216-109-00 RES-CHIP 330K 5% 1/10W
R530 1-216-077-91 RES-CHIP 15K 5% 1/10W
R532 1-215-437-00 METAL 4.7K 1% 1/4W
R533 1-215-457-00 METAL 33K 1% 1/4W
R534 1-215-458-00 METAL 36K 1% 1/4W
R535 1-249-441-11 CARBON 100K 5% 1/4W
!
R536 1-214-798-21 METAL 1.8 1% 1/2W
!
R538 1-215-889-00 METAL OXIDE 330 5% 2W
!
R539 1-249-385-11 CARBON 2.2 5% 1/4W
R540 1-215-445-00 METAL 10K 1% 1/4W
R541 1-249-429-11 CARBON 10K 5% 1/4W
R543 1-247-887-00 CARBON 220K 5% 1/4W
!
R544 1-249-377-11 CARBON 0.47 5% 1/4W
R545 1-215-873-00 METAL OXIDE 4.7K 5% 1W
!
R546 1-249-377-11 CARBON 0.47 5% 1/4W
R547 1-216-455-21 METAL OXIDE 560 5% 2W
R548 1-216-377-11 METAL OXIDE 4.7 5% 2W
!
R549 1-260-288-11 CARBON 0.47 5% 1/2W
!
R550 1-260-288-11 CARBON 0.47 5% 1/2W
R551 1-215-907-11 METAL OXIDE 22 5% 3W
!
R553 1-216-363-00 METAL OXIDE 0.33 5% 2W
!
R554 1-249-429-11 CARBON 10K 5% 1/4W
!
R555 1-247-895-91 CARBON 470K 5% 1/4W
!
R556 1-249-417-11 CARBON 1K 5% 1/4W
!
R557 1-247-895-91 CARBON 470K 5% 1/4W
!
R558 1-216-097-11 RES-CHIP 100K 5% 1/10W
!
R559 1-216-073-00 RES-CHIP 10K 5% 1/10W
!
R560 1-215-879-11 METAL OXIDE 47K 5% 1W
!
R561 1-249-406-11 CARBON 120 5% 1/4W
!
R562 1-208-808-11 METAL CHIP 12K 0.50% 1/10W
!
R563 1-249-433-11 CARBON 22K 5% 1/4W
X!
R564 1-208-836-11 METAL CHIP 180K 0.50% 1/10W
!
R565 1-249-429-11 CARBON 10K 5% 1/4W
!
R566 1-216-073-00 RES-CHIP 10K 5% 1/10W
!
R567 1-216-073-00 RES-CHIP 10K 5% 1/10W
!
R568 1-215-882-00 METAL OXIDE 22 5% 2W
R569 1-214-798-21 METAL 1.8 1% 1/2W
R570 1-249-433-11 CARBON 22K 5% 1/4W
R571 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R572 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
!
R601 1-219-513-11 CARBON 4.7M 5% 1/2W
(KV-29FS13 ONLY)
R602 1-249-389-11 CARBON 4.7 5% 1/4W
A
