— 48 —
KV-29FS13 / 29FS13C
NOTE: The components identifi ed by shading and
!
mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
R603 1-215-485-00 METAL 470K 1% 1/4W
R607 1-215-859-00 METAL OXIDE 22 5% 1W
R608 1-240-205-11 CARBON 22M 5% 1/2W
R609 1-216-049-11 RES-CHIP 1K 5% 1/10W
R610 1-216-073-00 RES-CHIP 10K 5% 1/10W
R611 1-216-089-11 RES-CHIP 47K 5% 1/10W
R612 1-216-045-00 RES-CHIP 680 5% 1/10W
!
R613 1-219-512-11 CARBON 2.2M 5% 1/2W
R614 1-249-413-11 CARBON 470 5% 1/4W
!
R615 1-218-265-11 METAL 8.2M 5% 1W
(KV-29FS13C ONLY)
!
R616 1-260-302-51 CARBON 6.8 5% 1/2W
R617 1-216-009-91 RES-CHIP 22 5% 1/10W
R618 1-249-440-11 CARBON 82K 5% 1/4W
R619 1-249-437-11 CARBON 47K 5% 1/4W
R620 1-249-417-11 CARBON 1K 5% 1/4W
!
R621 1-240-251-11 CEMENTED 6.8 5% 10W
R622 1-249-441-11 CARBON 100K 5% 1/4W
!
R623 1-260-324-11 CARBON 470 5% 1/2W
!
R624 1-249-429-11 CARBON 10K 5% 1/4W
R625 1-249-437-11 CARBON 47K 5% 1/4W
!
R626 1-220-926-11 FUSIBLE 0.47 10% 1/2W
R627 1-215-479-00 METAL 270K 1% 1/4W
(KV-29FS13C ONLY)
R627 1-215-483-00 METAL 390K 1% 1/4W
(KV-29FS13 ONLY)
R628 1-215-479-00 METAL 270K 1% 1/4W
(KV-29FS13C ONLY)
R630 1-249-421-11 CARBON 2.2K 5% 1/4W
R631 1-215-929-11 METAL OXIDE 100K 5% 3W
(KV-29FS13C ONLY)
!
R632 1-216-361-00 METAL OXIDE 0.22 5% 2W
R633 1-249-415-11 CARBON 680 5% 1/4W
R634 1-216-073-00 RES-CHIP 10K 5% 1/10W
R635 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
!
R637 1-216-485-11 METAL OXIDE 5.6K 5% 3W
(KV-29FS13C ONLY)
R638 1-249-402-11 CARBON 56 5% 1/4W
(KV-29FS13C ONLY)
R638 1-249-399-11 CARBON 33 5% 1/4W
(KV-29FS13 ONLY)
R639 1-249-421-11 CARBON 2.2K 5% 1/4W
R640 1-249-417-11 CARBON 1K 5% 1/4W
!
R641 1-216-362-11 METAL OXIDE 0.27 5% 2W
R642 1-216-089-11 RES-CHIP 47K 5% 1/10W
R643 1-249-419-11 CARBON 1.5K 5% 1/4W
R644 1-247-843-11 CARBON 3.3K 5% 1/4W
R645 1-215-898-11 METAL OXIDE 10K 5% 2W
R646 1-249-419-11 CARBON 1.5K 5% 1/4W
R648 1-215-908-00 METAL OXIDE 33 5% 3W
R649 1-249-417-11 CARBON 1K 5% 1/4W
R650 1-216-387-11 METAL OXIDE 0.68 5% 3W
R651 1-249-429-11 CARBON 10K 5% 1/4W
R653 1-216-049-11 RES-CHIP 1K 5% 1/10W
R655 1-216-049-11 RES-CHIP 1K 5% 1/10W
R656 1-249-429-11 CARBON 10K 5% 1/4W
R658 1-216-387-11 METAL OXIDE 0.68 5% 3W
R659 1-215-857-11 METAL OXIDE 10 5% 1W
!
R660 1-216-485-11 METAL OXIDE 5.6K 5% 3W
(KV-29FS13C ONLY)
R660 1-215-924-00 METAL OXIDE 15K 5% 3W
(KV-29FS13 ONLY)
R661 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
!
R662 1-216-485-11 METAL OXIDE 5.6K 5% 3W
(KV-29FS13C ONLY)
R663 1-216-081-00 RES-CHIP 22K 5% 1/10W
R2001 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2002 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R2003 1-249-425-11 CARBON 4.7K 5% 1/4W
R2004 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R2005 1-216-295-11 SHORT
RELAY
!
RY601 1-755-198-11 RELAY
!
RY602 1-755-266-11 RELAY, AC POWER
SWITCH
S2007 1-762-816-11 SWITCH TACTILE
S2008 1-762-816-11 SWITCH TACTILE
SWITCH
SW501 1-572-707-11 SWITCH LEVER
SW502 1-572-707-11 SWITCH LEVER
TRANSFORMER
!
T501 1-437-195-11 TRANSFORMER, HORIZONTAL DRIVE
!
T503 1-426-981-11 TRANSFORMER, FERRITE (PMT)
!
T504 1-431-693-11 TRANSFORMER, HORIZONTAL LINEAR
!
T505 1-453-310-11 FBT ASSY NX-4521//X4J4
!
T602 1-426-717-11 TRANSFORMER, LINE FILTER (LFT)
!
T603 1-433-807-21 TRANSFORMER, REGULAT
(KV-29FS13C ONLY)
!
T603 1-433-806-11 TRANSFORMER, REGULAT
(KV-29FS13 ONLY)
!
T604 1-431-852-11 TRANSFORMER, CONVERTER (SRT)
