KV-29FS13 / 29FS13C
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
R855 1-216-089-11 RES-CHIP 47K 5% 1/10W
R860 1-208-806-11 METAL CHIP 10K 0.50% 1/10W
R862 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R863 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R864 1-216-033-00 RES-CHIP 220 5% 1/10W
R865 1-216-097-11 RES-CHIP 100K 5% 1/10W
R866 1-249-429-11 CARBON 10K 5% 1/4W
R867 1-216-073-00 RES-CHIP 10K 5% 1/10W
R868 1-216-073-00 RES-CHIP 10K 5% 1/10W
R869 1-216-097-11 RES-CHIP 100K 5% 1/10W
R870 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R871 1-215-489-00 METAL 680K 1% 1/4W
R872 1-216-121-11 RES-CHIP 1M 5% 1/10W
R873 1-216-073-00 RES-CHIP 10K 5% 1/10W
R874 1-216-037-00 RES-CHIP 330 5% 1/10W
R875 1-216-035-00 RES-CHIP 270 5% 1/10W
TRANSFORMER
T801 1-424-584-11 TRANSFORMER, DYNAMIC FOCUS
HX
* A-1372-817-A HX MOUNTED PC BOARD
CONNECTOR
* CN4001 1-564-518-11 PLUG, CONNECTOR 3P
RESISTOR
R4001 1-216-025-11 RES-CHIP 100 5% 1/10W
R4002 1-216-045-00 RES-CHIP 680 5% 1/10W
R4003 1-216-047-91 RES-CHIP 820 5% 1/10W
R4004 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4005 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
SWITCH
S4001 1-762-196-21 SWITCH TACTILE
S4002 1-762-196-21 SWITCH TACTILE
S4003 1-762-196-21 SWITCH TACTILE
S4004 1-762-196-21 SWITCH TACTILE
S4005 1-762-196-21 SWITCH TACTILE
S4006 1-762-196-21 SWITCH TACTILE
K
* A-1380-632-A K (VAR) MOUNTED PC BOARD
CAPACITOR
C201 1-126-963-11 ELECT 4.7µF 20% 50V
C202 1-126-963-11 ELECT 4.7µF 20% 50V
C404 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C405 1-163-034-00 CERAMIC CHIP 0.033µF 50V
C406 1-163-011-11 CERAMIC CHIP 0.0015µF 10% 50V
C407 1-164-222-11 CERAMIC CHIP 0.22µF 25V
C408 1-164-222-11 CERAMIC CHIP 0.22µF 25V
C409 1-163-011-11 CERAMIC CHIP 0.0015µF 10% 50V
C410 1-163-034-00 CERAMIC CHIP 0.033µF 50V
C411 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C412 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C413 1-126-963-11 ELECT 4.7µF 20% 50V
C414 1-126-963-11 ELECT 4.7µF 20% 50V
C415 1-126-963-11 ELECT 4.7µF 20% 50V
C416 1-126-963-11 ELECT 4.7µF 20% 50V
C417 1-126-963-11 ELECT 4.7µF 20% 50V
C418 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C419 1-164-346-11 CERAMIC CHIP 1µF 16V
C422 1-126-963-11 ELECT 4.7µF 20% 50V
C423 1-126-963-11 ELECT 4.7µF 20% 50V
C440 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C441 1-126-933-11 ELECT 100µF 20% 16V
C446 1-126-933-11 ELECT 100µF 20% 16V
C450 1-126-963-11 ELECT 4.7µF 20% 50V
C451 1-126-963-11 ELECT 4.7µF 20% 50V
C475 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C490 1-216-295-11 SHORT
CONNECTOR
* CN402 1-564-506-11 PLUG, CONNECTOR 3P
CN450 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
CN451 1-564-505-11 PLUG, CONNECTOR 2P
IC
IC404 8-759-697-77 IC NJW1130AG-TE2
CHIP CONDUCTOR
JR403 1-216-295-11 SHORT
JR404 1-216-295-11 SHORT
JR407 1-216-295-11 SHORT
JR408 1-216-295-11 SHORT
JR419 1-216-295-11 SHORT
JR420 1-216-295-11 SHORT
JR421 1-216-295-11 SHORT
