Sony Trinitron KV-29FS13 - Page 52

— 52 —
KV-29FS13 / 29FS13C
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
JR422 1-216-295-11 SHORT
JR425 1-216-295-11 SHORT
JR426 1-216-295-11 SHORT
JR427 1-216-295-11 SHORT
JR428 1-216-295-11 SHORT
JR429 1-216-295-11 SHORT
JR440 1-216-295-11 SHORT
JR460 1-216-295-11 SHORT
JR474 1-216-295-11 SHORT
JR491 1-216-295-11 SHORT
COIL
L410 1-414-271-11 INDUCTOR 47µH
TRANSISTOR
Q430 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q431 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q432 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q433 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R403 1-216-295-11 SHORT
R404 1-216-025-11 RES-CHIP 100 5% 1/10W
R405 1-216-025-11 RES-CHIP 100 5% 1/10W
R407 1-216-025-11 RES-CHIP 100 5% 1/10W
R409 1-216-025-11 RES-CHIP 100 5% 1/10W
R410 1-216-025-11 RES-CHIP 100 5% 1/10W
R431 1-216-073-00 RES-CHIP 10K 5% 1/10W
R432 1-216-073-00 RES-CHIP 10K 5% 1/10W
R433 1-216-295-11 SHORT
R434 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R435 1-216-033-00 RES-CHIP 220 5% 1/10W
R436 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R437 1-216-033-00 RES-CHIP 220 5% 1/10W
R438 1-216-033-00 RES-CHIP 220 5% 1/10W
R442 1-216-033-00 RES-CHIP 220 5% 1/10W
R443 1-216-105-91 RES-CHIP 220K 5% 1/10W
R444 1-216-105-91 RES-CHIP 220K 5% 1/10W
R445 1-216-105-91 RES-CHIP 220K 5% 1/10W
R446 1-216-105-91 RES-CHIP 220K 5% 1/10W
R455 1-216-081-00 RES-CHIP 22K 5% 1/10W
R456 1-216-081-00 RES-CHIP 22K 5% 1/10W
R468 1-216-295-11 SHORT
R469 1-216-295-11 SHORT
R470 1-216-025-11 RES-CHIP 100 5% 1/10W
MA
* A-1304-200-A MA (VAR) MOUNTED PC BOARD
CAPACITOR
C003 1-126-959-11 ELECT 0.47µF 20% 50V
C006 1-126-964-11 ELECT 10µF 20% 50V
C009 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C010 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C011 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C012 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C015 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C016 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C017 1-126-960-11 ELECT 1µF 20% 50V
C019 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C020 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C021 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C022 1-163-135-00 CERAMIC CHIP 560pF 5% 50V
C027 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C028 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C032 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C033 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C034 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C037 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C038 1-126-941-11 ELECT 470µF 20% 25V
C039 1-126-964-11 ELECT 10µF 20% 50V
C040 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C041 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C042 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C043 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C044 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C045 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C046 1-104-664-11 ELECT 47µF 20% 25V
C047 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C048 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C051 1-126-943-11 ELECT 2200µF 20% 25V
C060 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C062 1-126-959-11 ELECT 0.47µF 20% 50V
C063 1-137-194-81 FILM 0.47µF 5% 50V
C064 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C070 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C071 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C076 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C077 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C091 1-115-185-11 CERAMIC CHIP 0.033µF 10% 50V
C093 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
