Sony Trinitron KV-29FS13 - Page 53

— 53 —
KV-29FS13 / 29FS13C
NOTE: The components identifi ed by shading and
! mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
C097 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C099 1-126-960-11 ELECT 1µF 20% 50V
C302 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C303 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C304 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C305 1-126-933-11 ELECT 100µF 20% 16V
C307 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C308 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C309 1-126-933-11 ELECT 100µF 20% 16V
C311 1-163-123-00 CERAMIC CHIP 180pF 5% 50V
C313 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C314 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C315 1-104-664-11 ELECT 47µF 20% 25V
C316 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C317 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C318 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C319 1-126-767-11 ELECT 1000µF 20% 16V
C320 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C321 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C322 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C323 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C324 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C325 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C326 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C328 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C329 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C330 1-126-960-11 ELECT 1µF 20% 50V
C331 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C332 1-163-010-11 CERAMIC CHIP 0.0012µF 10% 50V
C334 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C335 1-126-963-11 ELECT 4.7µF 20% 50V
C336 1-104-664-11 ELECT 47µF 20% 25V
C338 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C339 1-126-960-11 ELECT 1µF 20% 50V
C340 1-126-933-11 ELECT 100µF 20% 16V
C341 1-163-233-11 CERAMIC CHIP 18pF 5% 50V
C348 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C350 1-126-959-11 ELECT 0.47µF 20% 50V
C351 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C352 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C353 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C354 1-126-933-11 ELECT 100µF 20% 16V
C355 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C356 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C357 1-104-664-11 ELECT 47µF 20% 25V
C358 1-104-664-11 ELECT 47µF 20% 25V
C359 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C360 1-126-959-11 ELECT 0.47µF 20% 50V
C361 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C362 1-104-664-11 ELECT 47µF 20% 25V
C363 1-163-038-11 CERAMIC CHIP 0.1µF 25V
C364 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C365 1-137-194-81 FILM 0.47µF 5% 50V
C366 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C367 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C368 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C369 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C370 1-126-933-11 ELECT 100µF 20% 16V
C371 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C377 1-126-963-11 ELECT 4.7µF 20% 50V
C380 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C381 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C382 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C389 1-115-185-11 CERAMIC CHIP 0.033µF 10% 50V
C390 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C391 1-126-933-11 ELECT 100µF 20% 16V
C395 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C396 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C397 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C398 1-126-964-11 ELECT 10µF 20% 50V
CONNECTOR
* CN001 1-564-511-11 PLUG, CONNECTOR 8P
* CN002 1-560-124-00 PLUG, CONNECTOR (2.5MM) 4P
* CN003 1-564-512-11 PLUG, CONNECTOR 9P
* CN004 1-564-512-11 PLUG, CONNECTOR 9P
* CN005 1-764-333-11 PLUG, CONNECTOR 10P
* CN006 1-764-333-11 PLUG, CONNECTOR 10P
* CN302 1-564-507-11 PLUG, CONNECTOR 4P
* CN309 1-564-506-11 PLUG, CONNECTOR 3P
DIODE
! D001 8-719-069-54 DIODE UDZSTE-175.1B
D002 8-719-110-17 DIODE MTZJ-T-77-10B
D003 8-719-073-01 DIODE MA111-TX
D004 8-719-069-54 DIODE UDZSTE-175.1B
D005 8-719-109-89 DIODE MTZJ-T-77-5.6C
D006 8-719-069-60 DIODE UDZSTE-175.1B
D075 8-719-073-01 DIODE MA111-TX
D301 8-719-921-44 DIODE MTZJ-T-77-5.1C
D305 8-719-921-44 DIODE MTZJ-T-77-5.1C
D360 8-719-914-44 DIODE DAP202K-T-146
FERRITE BEAD
FB001 1-414-234-22 FERRITE 0µH
FB002 1-414-234-22 FERRITE 0µH
FB301 1-412-911-11 FERRITE 0µH
MA
