— 54 —
KV-29FS13 / 29FS13C
NOTE: The components identifi ed by shading and
! mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
FILTER
FL301 1-239-847-11 FILTER, LOW PASS
FL302 1-239-847-11 FILTER, LOW PASS
FL303 1-239-847-11 FILTER, LOW PASS
IC
IC001 8-759-827-83 IC M37280MK-114SP
IC002 8-759-663-29 IC MM1476AF(TP)
IC003 8-759-699-33 IC M24C16-MN6T(A)
!
IC301 8-752-100-49 IC CXA2154AS
IC302 8-759-655-75 IC TC90A49P
CHIP CONDUCTOR
JR001 1-216-295-11 SHORT
JR002 1-216-295-11 SHORT
JR003 1-216-295-11 SHORT
JR005 1-216-295-11 SHORT
JR006 1-216-295-11 SHORT
JR007 1-216-295-11 SHORT
JR008 1-216-295-11 SHORT
JR010 1-216-295-11 SHORT
JR011 1-216-295-11 SHORT
JR090 1-216-295-11 SHORT
JR100 1-216-295-11 SHORT
JR101 1-216-295-11 SHORT
JR296 1-216-295-11 SHORT
JR297 1-216-295-11 SHORT
JR298 1-216-295-11 SHORT
JR310 1-216-295-11 SHORT
JR311 1-216-295-11 SHORT
JR355 1-216-295-11 SHORT
JR378 1-216-295-11 SHORT
JR379 1-216-295-11 SHORT
JR391 1-216-295-11 SHORT
JR399 1-216-295-11 SHORT
JR402 1-216-295-11 SHORT
JR501 1-216-295-11 SHORT
JR502 1-216-295-11 SHORT
COIL
L002 1-414-273-11 INDUCTOR 100µH
L003 1-414-273-11 INDUCTOR 100µH
L040 1-408-963-11 INDUCTOR 2.7µH
L301 1-414-267-11 INDUCTOR 10µH
L302 1-414-271-11 INDUCTOR 47µH
L303 1-414-856-11 INDUCTOR 10µH
L304 1-414-856-11 INDUCTOR 10µH
L305 1-414-267-11 INDUCTOR 10µH
L308 1-414-273-11 INDUCTOR 100µH
L310 1-414-273-11 INDUCTOR 100µH
L350 1-414-856-11 INDUCTOR 10µH
L351 1-414-856-11 INDUCTOR 10µH
TRANSISTOR
Q001 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q002 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q003 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q004 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q006 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q082 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q302 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q303 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q305 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q310 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q349 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q350 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q351 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q352 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q354 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q355 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q356 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q358 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q359 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q365 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q368 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q369 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q370 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q375 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q387 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q388 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q389 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R001 1-216-043-91 RES-CHIP 560 5% 1/10W
R002 1-216-041-00 RES-CHIP 470 5% 1/10W
R003 1-247-807-31 CARBON 100 5% 1/4W
R004 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R005 1-216-295-11 SHORT
R006 1-216-025-11 RES-CHIP 100 5% 1/10W
R007 1-216-025-11 RES-CHIP 100 5% 1/10W
R008 1-216-049-11 RES-CHIP 1K 5% 1/10W
R009 1-216-121-11 RES-CHIP 1M 5% 1/10W
R010 1-216-033-00 RES-CHIP 220 5% 1/10W
R011 1-216-033-00 RES-CHIP 220 5% 1/10W
R012 1-216-045-00 RES-CHIP 680 5% 1/10W
R013 1-249-417-11 CARBON 1K 5% 1/4W
R014 1-216-073-00 RES-CHIP 10K 5% 1/10W
R015 1-216-073-00 RES-CHIP 10K 5% 1/10W
