Sony Trinitron KV-29FS13 - Page 56

— 56 —
KV-29FS13 / 29FS13C
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
R318 1-216-091-00 RES-CHIP 56K 5% 1/10W
R319 1-216-081-00 RES-CHIP 22K 5% 1/10W
R320 1-216-025-11 RES-CHIP 100 5% 1/10W
R321 1-216-043-91 RES-CHIP 560 5% 1/10W
R322 1-216-025-11 RES-CHIP 100 5% 1/10W
R323 1-216-025-11 RES-CHIP 100 5% 1/10W
R324 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R326 1-208-806-11 METAL CHIP 10K 0.50% 1/10W
R327 1-216-025-11 RES-CHIP 100 5% 1/10W
R328 1-216-025-11 RES-CHIP 100 5% 1/10W
R329 1-216-025-11 RES-CHIP 100 5% 1/10W
R331 1-216-049-11 RES-CHIP 1K 5% 1/10W
R332 1-216-022-00 RES-CHIP 75 5% 1/10W
R333 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R334 1-216-025-11 RES-CHIP 100 5% 1/10W
R335 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R336 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R337 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R338 1-216-073-00 RES-CHIP 10K 5% 1/10W
R339 1-216-091-00 RES-CHIP 56K 5% 1/10W
R340 1-216-025-11 RES-CHIP 100 5% 1/10W
R341 1-216-089-11 RES-CHIP 47K 5% 1/10W
R342 1-216-049-11 RES-CHIP 1K 5% 1/10W
R343 1-216-097-11 RES-CHIP 100K 5% 1/10W
R344 1-216-295-11 SHORT
R345 1-216-097-11 RES-CHIP 100K 5% 1/10W
R346 1-216-097-11 RES-CHIP 100K 5% 1/10W
R347 1-216-025-11 RES-CHIP 100 5% 1/10W
R349 1-216-025-11 RES-CHIP 100 5% 1/10W
R351 1-216-041-00 RES-CHIP 470 5% 1/10W
R352 1-247-807-31 CARBON 100 5% 1/4W
R353 1-247-807-31 CARBON 100 5% 1/4W
R354 1-216-025-11 RES-CHIP 100 5% 1/10W
R355 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R356 1-216-025-11 RES-CHIP 100 5% 1/10W
R357 1-216-022-00 RES-CHIP 75 5% 1/10W
R358 1-216-093-91 RES-CHIP 68K 5% 1/10W
R359 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R360 1-216-093-91 RES-CHIP 68K 5% 1/10W
R361 1-216-022-00 RES-CHIP 75 5% 1/10W
R362 1-216-035-00 RES-CHIP 270 5% 1/10W
R363 1-216-039-00 RES-CHIP 390 5% 1/10W
R364 1-216-025-11 RES-CHIP 100 5% 1/10W
R365 1-216-025-11 RES-CHIP 100 5% 1/10W
R366 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R367 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R368 1-216-043-91 RES-CHIP 560 5% 1/10W
R369 1-216-033-00 RES-CHIP 220 5% 1/10W
R370 1-249-429-11 CARBON 10K 5% 1/4W
R372 1-216-039-00 RES-CHIP 390 5% 1/10W
R373 1-216-025-11 RES-CHIP 100 5% 1/10W
R374 1-216-025-11 RES-CHIP 100 5% 1/10W
R375 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R376 1-216-022-00 RES-CHIP 75 5% 1/10W
R377 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R378 1-216-295-11 SHORT
R379 1-216-049-11 RES-CHIP 1K 5% 1/10W
R382 1-216-295-11 SHORT
R383 1-216-295-11 SHORT
R384 1-216-295-11 SHORT
R386 1-216-047-91 RES-CHIP 820 5% 1/10W
R387 1-216-025-11 RES-CHIP 100 5% 1/10W
R388 1-216-025-11 RES-CHIP 100 5% 1/10W
R389 1-216-049-11 RES-CHIP 1K 5% 1/10W
R392 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R394 1-216-043-91 RES-CHIP 560 5% 1/10W
R395 1-216-043-91 RES-CHIP 560 5% 1/10W
R396 1-247-807-31 CARBON 100 5% 1/4W
R398 1-216-091-00 RES-CHIP 56K 5% 1/10W
R399 1-216-109-00 RES-CHIP 330K 5% 1/10W
CRYSTAL
X001 1-767-487-11 VIBRATOR, CRYSTAL
X301 1-567-505-11 OSCILLATOR, CRYSTAL
VA
* A-1342-550-A VA (VAR) MOUNTED PC BOARD
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C805 1-129-763-61 FILM 0.033µF 5% 200V
C811 1-129-765-00 FILM 0.047µF 5% 200V
C901 1-107-667-11 ELECT 2.2µF 20% 160V
C902 1-130-491-00 MYLAR 0.047µF 5% 50V
C903 1-126-935-11 ELECT 470µF 20% 10V
C904 1-130-471-00 MYLAR 0.001µF 5% 50V
C905 1-106-383-00 MYLAR 0.047µF 10% 200V
C906 1-130-471-00 MYLAR 0.001µF 5% 50V
C907 1-107-638-11 ELECT 33µF 20% 160V
C908 1-126-935-11 ELECT 470µF 20% 10V
C909 1-161-830-00 CERAMIC 0.0047µF 500V
C910 1-104-999-11 MYLAR 0.1µF 10% 200V
C911 1-104-665-11 ELECT 100µF 20% 10V
VA
MA
