Sony Trinitron KV-29FS13 - Page 57

— 57 —
KV-29FS13 / 29FS13C
Sony Corporation
Sony Technology Center
Technical Services
Service Promotion Deptartment
9-965-906-01
English
2001BS74101-1
Printed in USA
© 2001.3
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
C912 1-126-941-11 ELECT 470µF 20% 25V
C913 1-102-074-00 CERAMIC 0.001µF 10% 50V
C914 1-130-491-00 MYLAR 0.047µF 5% 50V
CONNECTOR
* CN901 1-564-508-11 PLUG, CONNECTOR 5P
* CN902 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
* CN904 1-564-507-11 PLUG, CONNECTOR 4P
DIODE
D804 8-719-302-43 DIODE RGP10GPKG23
D805 8-719-991-33 DIODE 1SS133T-77
D806 8-719-991-33 DIODE 1SS133T-77
D807 8-719-210-21 DIODE ERA82-004TP5
D901 8-719-110-88 DIODE MTZJ-T-77-39
D902 8-719-110-88 DIODE MTZJ-T-77-39
D903 8-719-991-33 DIODE 1SS133T-77
COIL
L801 1-406-989-21 INDUCTOR 10mH
L802 1-459-111-00 INDUCTOR 10mH
L901 1-412-528-11 INDUCTOR 18µH
TRANSISTOR
Q807 8-729-931-45 TRANSISTOR IRF614
Q808 8-729-140-97 TRANSISTOR 2SB734-T-34
Q901 8-729-017-06 TRANSISTOR 2SC4793
Q902 8-729-017-05 TRANSISTOR 2SA1837
Q903 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q904 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q905 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q906 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R818 1-216-025-11 RES-CHIP 100 5% 1/10W
R826 1-249-421-11 CARBON 2.2K 5% 1/4W
R876 1-216-049-11 RES-CHIP 1K 5% 1/10W
R901 1-249-401-11 CARBON 47 5% 1/4W
R902 1-249-386-11 CARBON 2.7 5% 1/4W
R903 1-249-414-11 CARBON 560 5% 1/4W
R904 1-249-432-11 CARBON 18K 5% 1/4W
R905 1-249-417-11 CARBON 1K 5% 1/4W
R906 1-249-432-11 CARBON 18K 5% 1/4W
R907 1-249-386-11 CARBON 2.7 5% 1/4W
R908 1-249-414-11 CARBON 560 5% 1/4W
R909 1-260-312-11 CARBON 47 5% 1/2W
R910 1-216-476-11 METAL OXIDE 180 5% 3W
R911 1-249-403-11 CARBON 68 5% 1/4W
R912 1-249-409-11 CARBON 220 5% 1/4W
R913 1-249-403-11 CARBON 68 5% 1/4W
R914 1-249-410-11 CARBON 270 5% 1/4W
R915 1-249-417-11 CARBON 1K 5% 1/4W
R916 1-249-417-11 CARBON 1K 5% 1/4W
R917 1-249-417-11 CARBON 1K 5% 1/4W
R918 1-247-807-31 CARBON 100 5% 1/4W
R919 1-247-807-31 CARBON 100 5% 1/4W
R920 1-249-416-11 CARBON 820 5% 1/4W
R921 1-249-429-11 CARBON 10K 5% 1/4W
R922 1-249-397-11 CARBON 22 5% 1/4W
R923 1-249-401-11 CARBON 47 5% 1/4W
ACCESSORIES AND PACKAGING
* 4-041-255-01 BAG, PROTECTION
* 4-075-478-02 CARTON, INDIVIDUAL
* 4-081-082-01 CUSHION ASSY, UPPER
* 4-081-083-01 CUSHION ASSY, LOWER
4-081-738-41 MANUAL, INSTRUCTION
REMOTE COMMANDER
1-476-680-11 REMOTE COMMANDER (RM-Y180)
4-978-977-11 BATTERY COVER (RM-Y180)
VA
