Sony Trinitron KV-29FV310 - Page 71

— 71 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R532 1-216-810-11 METAL CHIP 120 5% 1/10W
R533 1-215-879-11 METAL OXIDE 47K 5% 1W
R534 1-218-720-11 METAL CHIP 15K 0.50% 1/10W
(KV-36FV310 ONLY)
R536 1-260-288-11 CARBON 0.47 5% 1/2W
R537 1-260-288-11 CARBON 0.47 5% 1/2W
R538 1-247-887-00 CARBON 220K 5% 1/4W
R545 1-249-387-11 CARBON 3.3 5% 1/4W
R553 1-249-377-11 CARBON 0.47 5% 1/4W
R558 1-218-720-11 METAL CHIP 15K 0.50% 1/10W
(KV-36FV310 ONLY)
R559 1-216-805-11 METAL CHIP 47 5% 1/10W
R561 1-215-445-00 METAL 10K 1% 1/4W
R563 1-214-798-21 METAL 1.8 1% 1/2W
R564 1-247-895-91 CARBON 470K 5% 1/4W
R565 1-215-889-00 METAL OXIDE 330 5% 2W
R566 1-218-710-11 METAL CHIP 5.6K 0.50% 1/10W
(KV-32FV310 ONLY)
R566 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R566 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
(KV-36FV310 ONLY)
R567 1-249-385-11 CARBON 2.2 5% 1/4W
R568 1-218-710-11 METAL CHIP 5.6K 0.50% 1/10W
(KV-32FV310 ONLY)
R568 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R568 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
(KV-36FV310 ONLY)
R569 1-215-445-00 METAL 10K 1% 1/4W
R570 1-216-845-11 METAL CHIP 100K 5% 1/10W
R571 1-216-837-11 METAL CHIP 22K 5% 1/10W
R572 1-216-837-11 METAL CHIP 22K 5% 1/10W
R573 1-216-845-11 METAL CHIP 100K 5% 1/10W
R574 1-214-798-21 METAL 1.8 1% 1/2W
R576 1-215-905-11 METAL OXIDE 10 5% 3W
(KV-32FV310/36FV310 ONLY)
R576 1-215-907-11 METAL OXIDE 22 5% 3W
(KV-27FV310/29FV310 ONLY)
R577 1-216-821-11 METAL CHIP 1K 5% 1/10W
R578 1-214-798-21 METAL 1.8 1% 1/2W
R583 1-216-833-11 METAL CHIP 10K 5% 1/10W
R584 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R585 1-216-821-11 METAL CHIP 1K 5% 1/10W
R586 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R587 1-216-809-11 METAL CHIP 100 5% 1/10W
R588 1-216-821-11 METAL CHIP 1K 5% 1/10W
R590 1-216-809-11 METAL CHIP 100 5% 1/10W
R591 1-249-417-11 CARBON 1K 5% 1/4W
R592 1-216-363-00 METAL OXIDE 0.33 5% 2W
R593 1-249-417-11 CARBON 1K 5% 1/4W
(KV-27FV310/29FV310 ONLY)
R593 1-249-420-11 CARBON 1.8K 5% 1/4W
(KV-32FV310/36FV310 ONLY)
R594 1-249-429-11 CARBON 10K 5% 1/4W
R595 1-247-891-00 CARBON 330K 5% 1/4W
R596 1-249-441-11 CARBON 100K 5% 1/4W
R597 1-216-864-11 SHORT CHIP
R598 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R599 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R900 1-216-821-11 METAL CHIP 1K 5% 1/10W
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R903 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R904 1-216-818-11 METAL CHIP 560 5% 1/10W
R905 1-216-817-11 METAL CHIP 470 5% 1/10W
R906 1-216-821-11 METAL CHIP 1K 5% 1/10W
R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
R908 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R909 1-249-417-11 CARBON 1K 5% 1/4W
R910 1-216-833-11 METAL CHIP 10K 5% 1/10W
R912 1-249-417-11 CARBON 1K 5% 1/4W
R932 1-218-285-11 METAL CHIP 75 5% 1/10W
R934 1-218-285-11 METAL CHIP 75 5% 1/10W
R940 1-247-807-31 CARBON 100 5% 1/4W
R941 1-247-807-31 CARBON 100 5% 1/4W
R942 1-216-841-11 METAL CHIP 47K 5% 1/10W
R947 1-216-864-11 SHORT CHIP
R950 1-216-809-11 METAL CHIP 100 5% 1/10W
R951 1-216-813-11 METAL CHIP 220 5% 1/10W
R953 1-218-285-11 METAL CHIP 75 5% 1/10W
R6001 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6002 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6004 1-249-417-11 CARBON 1K 5% 1/4W
SWITCH
S501 1-572-707-11 SWITCH, LEVER
S502 1-572-707-11 SWITCH, LEVER
A
