— 72 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
TRANSFORMER
T501 1-433-836-11 TRANSFORMER, HORIZONTAL DRIVE
T502 1-435-869-11 TRANFORMER, FERRITE (PMT)
T505 1-433-850-11 TRANSFORMER, HORIZONTAL LINEAR
(KV-27FV310/29FV310 ONLY)
T505 1-435-098-21 TRANSFORMER, HORIZONTAL LINEAR
(KV-32FV310/36FV310 ONLY)
T510 1-439-767-11 HORIZONTAL OUTPUT TRANSFORMER
(KV-27FV310/29FV310 ONLY)
T510 1-439-848-11 HORIZONTAL OUTPUT TRANSFORMER
(KV-32FV310/36FV310 ONLY)
THERMISTOR
TH501 1-800-193-00 THERMISTOR
TUNER
TU001 8-598-593-50 TUNER, FSS BTF-WA421
CRYSTAL
X001 1-795-572-11 VIBRATOR, CRYSTAL
X301 1-567-505-11 OSCILLATOR, CRYSTAL
HR
* A-1400-251-A HR (COM) BOARD, MOUNTED
CAPACITOR
C3001 1-104-665-11 ELECT 100µF 20% 25V
CONNECTOR
* CN3001 1-564-521-11 PLUG, CONNECTOR 6P
DIODE
D3002 8-719-057-09 DIODE LNJ801LPDJA
IC
IC3001 8-742-211-20 HYB IC SBX3071-71
RESISTOR
R3001 1-249-417-11 CARBON 1K 5% 1/4W
R3014 1-247-807-31 CARBON 100 5% 1/4W
SWITCH
S3006 1-786-338-11 SWITCH, TACTILE
BC
* A-1400-450-A BC BOARD, MOUNTED
CAPACITOR
C3355 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C3356 1-126-964-11 ELECT 10µF 20% 50V
C3357 1-113-619-11 CERAMIC CHIP 0.47µF 10V
C3358 1-126-940-11 ELECT 330µF 20% 25V
C3359 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C3360 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3361 1-162-922-11 CERAMIC CHIP 39pF 5% 50V
C3369 1-126-967-11 ELECT 47µF 20% 50V
C3370 1-126-964-11 ELECT 10µF 20% 50V
C3371 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C3398 1-126-961-11 ELECT 2.2µF 20% 50V
C3504 1-162-920-11 CERAMIC CHIP 27pF 5% 50V
C3505 1-162-920-11 CERAMIC CHIP 27pF 5% 50V
C3506 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3507 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3509 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3510 1-164-392-11 CERAMIC CHIP 390pF 5% 50V
C3511 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3512 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3513 1-216-864-11 SHORT CHIP
C3514 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3515 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3516 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3517 1-126-924-11 ELECT 330µF 20% 10V
C3518 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3519 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3520 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3521 1-162-920-11 CERAMIC CHIP 27pF 5% 50V
C3522 1-126-947-11 ELECT 47µF 20% 35V
C3523 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3524 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3525 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3526 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3527 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3528 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3529 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3530 1-126-947-11 ELECT 47µF 20% 35V
C3531 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3532 1-126-964-11 ELECT 10µF 20% 50V
A
HR BC
