KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
R3088 1-218-775-11 METAL CHIP 910K 0.50% 1/10W
R3089 1-240-913-91 RES-CHIP 3.9M 5% 1/10W
R3090 1-216-864-11 SHORT CHIP
R3094 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3095 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3096 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3097 1-216-864-11 SHORT CHIP
R3098 1-216-845-11 METAL CHIP 100K 5% 1/10W
CRYSTAL
X3001 1-579-583-11 VIBRATOR, CERAMIC
X3002 1-795-976-11 VIBRATOR, CRYSTAL
HU
* A-1404-855-A HU (VAR) BOARD, MOUNTED
CAPACITOR
C2234 1-137-194-81 FILM 0.47µF 5% 50V
C2235 1-137-194-81 FILM 0.47µF 5% 50V
C2240 1-126-959-11 ELECT 0.47µF 20% 50V
C2241 1-126-959-11 ELECT 0.47µF 20% 50V
CONNECTOR
* CN1001 1-564-506-11 PLUG, CONNECTOR 3P
* CN1003 1-564-511-11 PLUG, CONNECTOR 8P
DIODE
D301 8-719-108-12 DIODE RD9.1EW
D302 8-719-108-12 DIODE RD9.1EW
D2235 8-719-108-12 DIODE RD9.1EW
D2236 8-719-108-12 DIODE RD9.1EW
JACK
J2231 1-794-048-11 JACK, PIN 3P
J2232 1-694-242-11 TERMINAL, S
RESISTOR
R1001 1-249-425-11 CARBON 4.7K 5% 1/4W
R1002 1-249-420-11 CARBON 1.8K 5% 1/4W
R1003 1-249-417-11 CARBON 1K 5% 1/4W
R2008 1-249-425-11 CARBON 4.7K 5% 1/4W
R2009 1-249-420-11 CARBON 1.8K 5% 1/4W
R2010 1-249-417-11 CARBON 1K 5% 1/4W
R2011 1-249-416-11 CARBON 820 5% 1/4W
R2235 1-249-409-11 CARBON 220 5% 1/4W
R2236 1-249-441-11 CARBON 100K 5% 1/4W
R2237 1-249-409-11 CARBON 220 5% 1/4W
R2238 1-249-441-11 CARBON 100K 5% 1/4W
R2239 1-247-804-11 CARBON 75 5% 1/4W
R2240 1-247-804-11 CARBON 75 5% 1/4W
R2241 1-247-804-11 CARBON 75 5% 1/4W
SWITCH
S1007 1-762-816-11 SWITCH, TACTILE
S1008 1-762-816-11 SWITCH, TACTILE
S2001 1-692-431-21 SWITCH, TACTILE
S2002 1-692-431-21 SWITCH, TACTILE
S2003 1-692-431-21 SWITCH, TACTILE
S2004 1-692-431-21 SWITCH, TACTILE
S2005 1-692-431-21 SWITCH, TACTILE
HD
* A-1404-896-A HD BOARD, MOUNTED (SPACER BOARD)
(KV-32FV310/36FV310 ONLY)
D
* A-1404-852-A D (VAR) BOARD, MOUNTED
(KV-27FV310/29FV310(N) ONLY)
* A-1404-897-A D (VAR) BOARD, MOUNTED
(KV-32FV310/36FV310 ONLY)
* A-1405-114-A D (VAR) BOARD, MOUNTED
(KV-27FV310(S) ONLY)
The high-voltage leads associated with the FBT on the D board are not included and
must be ordered separately. Order the following leads when requesting this D board:
!
1-251-374-14 CAP ASSY, HIGH-VOLTAGE
(KV-27FV310/29FV310 ONLY)
!
1-251-715-22 CAP ASSY, HIGH-VOLTAGE
(KV-32FV310 ONLY)
!
1-251-715-32 CAP ASSY, HIGH-VOLTAGE
(KV-36FV310 ONLY)
!
1-900-805-19 WIRE ASSY, FOCUS HV
!
1-900-805-22 CONNECTOR ASSY, G2 HV
3-710-578-01 COVER, VOLUME, 6 MOLD
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C8001 1-126-964-11 ELECT 10µF 20% 50V
C8002 1-126-964-11 ELECT 10µF 20% 50V
C8003 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8004 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8006 1-126-960-11 ELECT 1µF 20% 50V
Y
HD
D
HU
