KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
C8007 1-162-971-11 CERAMIC CHIP 0.001µF 10% 50V
C8009 1-104-665-11 ELECT 100µF 20% 25V
C8012 1-126-947-11 ELECT 47µF 20% 35V
C8015 1-126-947-11 ELECT 47µF 20% 35V
C8016 1-130-495-00 MYLAR 0.1µF 5% 50V
C8017 1-126-964-11 ELECT 10µF 20% 50V
C8018 1-126-964-11 ELECT 10µF 20% 50V
C8020 1-130-495-00 MYLAR 0.1µF 5% 50V
C8021 1-162-971-11 CERAMIC CHIP 0.001µF 10% 50V
C8024 1-126-967-11 ELECT 47µF 20% 50V
C8025 1-126-947-11 ELECT 47µF 20% 35V
C8027 1-130-495-00 MYLAR 0.1µF 5% 50V
C8028 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C8030 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8031 1-128-551-11 ELECT 22µF 20% 63V
C8032 1-136-813-11 FILM 680pF 5% 100V
C8033 1-126-964-11 ELECT 10µF 20% 50V
C8035 1-162-115-00 CERAMIC 330pF 10% 1KV
C8036 1-162-115-00 CERAMIC 330pF 10% 1KV
C8037 1-165-953-11 FILM 47000pF 3% 800V
C8040 1-126-969-11 ELECT 220µF 20% 50V
C8041 1-130-495-00 MYLAR 0.1µF 5% 50V
C8042 1-136-189-00 MYLAR 0.1µF 10% 250V
C8045 1-130-471-00 MYLAR 0.001µF 5% 50V
C8048 1-130-495-00 MYLAR 0.1µF 5% 50V
C8063 1-165-607-91 FILM 10000pF 3% 800V
C8065 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C8073 1-162-962-11 CERAMIC CHIP 470pF 10% 50V
C8075 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8076 1-126-963-11 ELECT 4.7µF 20% 50V
C8077 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8080 1-117-228-71 MYLAR 2.2µF 10% 450V
C8139 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C8301 1-104-665-11 ELECT 100µF 20% 25V
C8302 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8407 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C8411 1-126-965-91 ELECT 22µF 20% 50V
C8412 1-137-194-81 FILM 0.47µF 5% 50V
C8413 1-100-120-51 ELECT 1000µF 20% 35V
C8415 1-126-963-11 ELECT 4.7µF 20% 50V
C8420 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C8421 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C8423 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C8424 1-162-969-11 CERAMIC CHIP 0.0068µF 10% 25V
C8425 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8426 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C8427 1-126-947-11 ELECT 47µF 20% 35V
C8428 1-126-943-11 ELECT 2200µF 20% 25V
C8430 1-126-960-11 ELECT 1µF 20% 50V
C8512 1-129-709-91 FILM 0.0039µF 5% 630V
(KV-27FV310/29FV310(N) ONLY)
C8512 1-129-928-00 FILM 0.0027µF 10% 630V
(KV-32FV310/36FV310 ONLY)
C8512 1-136-558-11 FILM 0.0039µF 5% 630V
(KV-29FV310(S) ONLY)
C8542 1-102-244-00 CERAMIC 220pF 500V
(KV-27FV310/29FV310 ONLY)
C8544 1-129-718-00 FILM 0.022µF 5% 630V
C8550 1-102-002-00 CERAMIC 680pF 500V
(KV-27FV310/29FV310 ONLY)
C8550 1-164-645-11 CERAMIC 1000pF 500V
(KV-32FV310/36FV310 ONLY)
C8551 1-109-954-11 ELECT 0.47µF 20% 160V
C8552 1-102-244-00 CERAMIC 220pF 10% 500V
C8573 1-104-665-11 ELECT 100µF 20% 25V
CONNECTOR
CN8004 1-695-915-11 TAB (CONTACT)
* CN8402 1-564-510-11 PLUG, CONNECTOR 7P
* CN8601 1-580-843-11 PIN, CONNECTOR (POWER)
CN8603 1-564-320-00 PIN, CONNECTOR(3.96MM PITCH) 2P
* CN8604 1-564-511-11 PLUG, CONNECTOR 8P
* CN8605 1-564-507-11 PLUG, CONNECTOR 4P
DIODE
D5007 8-719-404-50 DIODE MA111-TX
D8001 8-719-404-50 DIODE MA111-TX
D8003 8-719-404-50 DIODE MA111-TX
D8005 8-719-404-50 DIODE MA111-TX
D8006 8-719-063-74 DIODE D1NL20U-TR2
D8007 8-719-404-50 DIODE MA111-TX
D8009 8-719-083-83 DIODE UDZS-TE17-15B
D8010 8-719-979-64 DIODE µF4005PKG23
D8011 8-719-110-41 DIODE RD15ESB2
D8012 8-719-110-41 DIODE RD15ESB2
D8013 8-719-083-83 DIODE UDZS-TE17-15B
D8014 8-719-083-83 DIODE UDZS-TE17-15B
D8015 8-719-404-50 DIODE MA111-TX
D8019 8-719-109-85 DIODE RD5.1ESB2
! D8022 8-719-063-74 DIODE D1NL20U-TR2
