77
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
C269 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C270 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C271 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C272 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C273 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C274 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C275 1-164-346-11 CERAMIC CHIP 1MF 16V
C276 1-164-346-11 CERAMIC CHIP 1MF 16V
C277 1-164-346-11 CERAMIC CHIP 1MF 16V
C278 1-164-346-11 CERAMIC CHIP 1MF 16V
C279 1-126-965-11 ELECT 22MF 20% 50V
C280 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C281 1-126-965-11 ELECT 22MF 20% 50V
C282 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C288 1-163-117-91 CERAMIC CHIP 100PF 5% 50V
C300 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C301 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C302 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C303 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C304 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C305 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C306 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C307 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C308 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C309 1-164-346-11 CERAMIC CHIP 1MF 16V
C310 1-164-346-11 CERAMIC CHIP 1MF 16V
C311 1-164-346-11 CERAMIC CHIP 1MF 16V
C312 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C315 1-216-295-91 SHORT 0
C317 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C319 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C320 1-126-965-11 ELECT 22MF 20% 50V
C321 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C322 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C323 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C324 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C325 1-164-346-11 CERAMIC CHIP 1MF 16V
C326 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C327 1-130-770-00 FILM 0.15MF 5% 63V
C328 1-126-965-11 ELECT 22MF 20% 50V
C329 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C330 1-137-581-11 FILM 0.1MF 5% 100V
C331 1-137-581-11 FILM 0.1MF 5% 100V
C332 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C333 1-126-933-11 ELECT 100MF 20% 16V
C334 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C335 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C336 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C337 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C338 1-164-346-11 CERAMIC CHIP 1MF 16V
C339 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C340 1-126-933-11 ELECT 100MF 20% 16V
C341 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C342 1-164-346-11 CERAMIC CHIP 1MF 16V
C343 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C347 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C348 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C350 1-126-964-11 ELECT 10MF 20% 50V
C351 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C352 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C353 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C354 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C355 1-126-965-11 ELECT 22MF 20% 50V
C356 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C357 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C358 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C359 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C360 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C370 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C371 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C372 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C373 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C534 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C1001 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1002 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1010 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C1013 1-126-965-11 ELECT 22MF 20% 50V
C1014 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C1015 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C1020 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
< CONNECTOR >
CN1 1-695-302-11 CONNECTOR, BOARD TO BOARD 50P
CN2 *1-564-508-11 PLUG, CONNECTOR 5P
CN4 *1-568-879-11 PIN, CONNECTOR 4P
CN5 1-695-915-11 TAB (CONTACT)
CN201 1-766-296-21 CONNECTOR, DUAL SCART
CN301 *1-568-882-51 PIN, CONNECTOR 7P
CN303 *1-568-880-51 PIN, CONNECTOR 5P
< DIODE >
D2 8-719-988-61 DIODE 1SS355TE-17
D16 8-719-988-61 DIODE 1SS355TE-17
D30 8-719-988-61 DIODE 1SS355TE-17
A
