78
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
D101 8-719-977-81 DIODE DTZ33B
D201 8-719-069-60 DIODE UDZS-TE17-9.1B
D202 8-719-069-60 DIODE UDZS-TE17-9.1B
D203 8-719-069-60 DIODE UDZS-TE17-9.1B
D204 8-719-069-60 DIODE UDZS-TE17-9.1B
D205 8-719-069-60 DIODE UDZS-TE17-9.1B
D206 8-719-069-60 DIODE UDZS-TE17-9.1B
D207 8-719-069-60 DIODE UDZS-TE17-9.1B
D208 8-719-069-60 DIODE UDZS-TE17-9.1B
D209 8-719-069-60 DIODE UDZS-TE17-9.1B
D210 8-719-069-60 DIODE UDZS-TE17-9.1B
D211 8-719-069-60 DIODE UDZS-TE17-9.1B
D212 8-719-069-60 DIODE UDZS-TE17-9.1B
D213 8-719-069-60 DIODE UDZS-TE17-9.1B
D214 8-719-069-60 DIODE UDZS-TE17-9.1B
D215 8-719-069-60 DIODE UDZS-TE17-9.1B
D216 8-719-069-55 DIODE UDZS-TE17-5.6B
D217 8-719-069-55 DIODE UDZS-TE17-5.6B
D218 8-719-069-55 DIODE UDZS-TE17-5.6B
D220 8-719-988-61 DIODE 1SS355TE-17
D221 8-719-988-61 DIODE 1SS355TE-17
D222 8-719-069-60 DIODE UDZS-TE17-9.1B
D223 8-719-069-60 DIODE UDZS-TE17-9.1B
D224 8-719-069-60 DIODE UDZS-TE17-9.1B
D225 8-719-069-60 DIODE UDZS-TE17-9.1B
D226 8-719-069-60 DIODE UDZS-TE17-9.1B
D227 8-719-977-13 DIODE DTZ6.8C
D251 8-719-047-16 DIODE BAS216
D302 8-719-988-61 DIODE 1SS355TE-17
D303 8-719-069-55 DIODE UDZS-TE17-5.6B
D304 8-719-069-55 DIODE UDZS-TE17-5.6B
D320 8-719-069-60 DIODE UDZS-TE17-9.1B
D331 8-719-069-55 DIODE UDZS-TE17-5.6B
D370 8-719-047-16 DIODE BAS216
D401 8-719-069-57 DIODE UDZS-TE17-6.8B
D402 8-719-988-61 DIODE 1SS355TE-17
D1010 8-719-036-58 DIODE MA3030-H(TX)
< ENCAPSULATED FILTER >
FL101 1-236-071-11 ENCAPSULATED COMPONENT
FL201 1-236-071-11 ENCAPSULATED COMPONENT
FL202 1-236-071-11 ENCAPSULATED COMPONENT
FL203 1-236-071-11 ENCAPSULATED COMPONENT
FL1001 1-236-071-11 ENCAPSULATED COMPONENT
< IC >
IC1 8-759-376-77 IC SDA30C263-GEG
IC2 8-759-524-94 IC M24C32-MW6T
IC3 8-759-641-72 IC M27C2001
IC4 8-759-394-57 IC PST593C-MMP-4P
IC201 8-752-081-26 IC CXA2040AQ-T4
IC205 8-759-394-57 IC PST593C-MMP-4P
IC301 8-752-081-43 IC CXA2076Q-TL
IC302 8-759-565-20 IC TDA4665T/V5-118
IC1001 8-759-584-20 IC SDA5273
< COIL >
L111 1-410-993-22 INDUCTOR CHIP 1UH
L120 1-408-602-31 INDUCTOR 8.2UH
L121 1-408-591-21 INDUCTOR 1UH
L122 1-408-602-31 INDUCTOR 8.2UH
L300 1-408-607-21 INDUCTOR 22UH
< TRANSISTOR >
Q1 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q4 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q15 8-729-026-49 TRANSISTOR 2SA1037AK
Q30 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q80 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q81 8-729-026-49 TRANSISTOR 2SA1037AK
Q82 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q110 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q111 8-729-026-49 TRANSISTOR 2SA1037AK
Q112 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q120 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q122 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q140 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q141 8-729-026-49 TRANSISTOR 2SA1037AK
Q201 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q203 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q204 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q300 1-801-806-11 TRANSISTOR DTC144EKA
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 1-801-806-11 TRANSISTOR DTC144EKA
Q330 8-729-026-49 TRANSISTOR 2SA1037AK
Q331 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q332 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q333 8-729-026-49 TRANSISTOR 2SA1037AK
Q334 8-729-026-49 TRANSISTOR 2SA1037AK
Q335 8-729-026-49 TRANSISTOR 2SA1037AK
