Sony TRINITRON KV-34FV15 - Page 71

— 105 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
R430 1-208-794-11 RES, CHIP 3.3K 0.50% 1/10W
R431 1-208-794-11 RES, CHIP 3.3K 0.50% 1/10W
R432 1-208-821-11 RES, CHIP 43K 0.50% 1/10W
R433 1-216-059-00 RES, CHIP 2.7K 5% 1/10W
R434 1-216-059-00 RES, CHIP 2.7K 5% 1/10W
R435 1-216-001-00 RES, CHIP 10 5% 1/10W
R436 1-216-001-00 RES, CHIP 10 5% 1/10W
R437 1-216-001-00 RES, CHIP 10 5% 1/10W
R438 1-216-001-00 RES, CHIP 10 5% 1/10W
R439 1-216-059-00 RES, CHIP 2.7K 5% 1/10W
R460 1-216-059-00 RES, CHIP 2.7K 5% 1/10W
T
