Sony TRINITRON KV-34FV15 - WA BOARD COMPLETE PARTS LIST (All Models)

— 121 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
* A-1375-187-A WA BOARD, COMPLETE (All Models)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C941 1-126-942-61 ELECT 1000µF 20% 25V
C944 1-126-964-11 ELECT 10µF 20% 50V
C946 1-104-665-11 ELECT 100µF 20% 25V
C947 1-104-664-11 ELECT 47µF 20% 25V
C949 1-161-830-00 CERAMIC 0.0047µF 500V
C950 1-126-941-11 ELECT 470µF 20% 25V
C951 1-107-645-11 ELECT 22µF 20% 160V
C952 1-104-999-11 MYLAR 0.1µF 10% 200V
C953 1-106-383-00 MYLAR 0.047µF 10% 200V
C954 1-130-471-00 FILM 0.001µF 5% 50V
C955 1-107-667-11 ELECT 2.2µF 20% 160V
C956 1-130-471-00 FILM 0.001µF 5% 50V
C957 1-106-383-00 MYLAR 0.047µF 10% 200V
C958 1-126-941-11 ELECT 470µF 20% 25V
C960 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C961 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C962 1-126-964-11 ELECT 10µF 20% 50V
C963 1-126-964-11 ELECT 10µF 20% 50V
C964 1-110-501-11 CERAMIC CHIP 0.33µF 10% 16V
C965 1-104-664-11 ELECT 47µF 20% 25V
C966 1-126-960-11 ELECT 1µF 20% 50V
C967 1-126-964-11 ELECT 10µF 20% 50V
C968 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C970 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C971 1-104-664-11 ELECT 47µF 20% 25V
C972 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C973 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C974 1-137-370-11 FILM 0.01µF 5% 50V
C976 1-130-967-00 FILM 0.0027µF 5% 50V
C977 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C1941 1-126-941-11 ELECT 470µF 20% 25V
C1946 1-136-165-00 FILM 0.1µF 5% 50V
C1947 1-136-165-00 FILM 0.1µF 5% 50V
C1948 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C1949 1-126-934-11 ELECT 220µF 20% 16V
C1961 1-129-725-00 FILM 0.082µF 5% 400V
C1962 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1965 1-136-601-11 FILM 0.01µF 5% 630V
C1966 1-137-378-11 FILM 0.22µF 5% 50V
C1968 1-137-378-11 FILM 0.22µF 5% 50V
C1972 1-104-664-11 ELECT 47µF 20% 25V
C1974 1-104-664-11 ELECT 47µF 20% 25V
WA
CONNECTOR
CN941 * 1-564-511-11 PLUG, CONNECTOR 8P
CN942 * 1-564-508-11 PLUG, CONNECTOR 5P
CN961 * 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
CN981 * 1-564-506-11 PLUG, CONNECTOR 3P
DIODE
D941 8-719-991-33 DIODE 1SS133T-77
D943 8-719-991-33 DIODE 1SS133T-77
D944 8-719-991-33 DIODE 1SS133T-77
D945 8-719-109-89 DIODE RD5.6ESB2
D946 8-719-110-88 DIODE RD39ESB2
D947 8-719-110-88 DIODE RD39ESB2
D962 8-719-991-33 DIODE 1SS133T-77
D963 8-719-404-50 DIODE MA111-TX
D964 8-719-210-21 DIODE 11EQS04
D966 8-719-302-43 DIODE EL1Z
D1961 8-719-991-33 DIODE 1SS133T-77
D1962 8-719-991-33 DIODE 1SS133T-77
IC
IC961 8-759-803-42 IC LA6500-FA
IC962 8-759-729-03 IC NJM2903D
IC963 8-759-729-03 IC NJM2903D
IC964 8-759-700-42 IC NJM2904D
IC965 8-759-701-59 IC NJM78M09FA
COIL
L961 1-459-111-00 INDUCTOR 10MMH
L964 1-406-989-21 INDUCTOR 10MMH
TRANSISTOR
Q941 8-729-422-27 TRANSISTOR 2SD601A-Q
Q942 8-729-216-22 TRANSISTOR 2SA1162-G
Q943 8-729-422-27 TRANSISTOR 2SD601A-Q
Q944 8-729-422-27 TRANSISTOR 2SD601A-Q
Q945 8-729-422-27 TRANSISTOR 2SD601A-Q
Q946 8-729-045-05 TRANSISTOR 2SA2005
Q947 8-729-045-04 TRANSISTOR 2SC5511
Q948 8-729-422-27 TRANSISTOR 2SD601A-Q
Q949 8-729-216-22 TRANSISTOR 2SA1162-G
Q961 8-729-422-27 TRANSISTOR 2SD601A-Q
Q962 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q963 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q965 8-729-931-45 TRANSISTOR IRF614
Q966 8-729-216-22 TRANSISTOR 2SA1162-G
Q967 8-729-140-97 TRANSISTOR 2SB734-34
Q968 8-729-422-27 TRANSISTOR 2SD601A-Q
Q969 8-729-422-27 TRANSISTOR 2SD601A-Q
WA
