REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
MAIN SCHEMATIC (FOR UY PIP COMPONENTS SEE PAGE 119)
* A-1394-938-A UY BOARD, COMPLETE
(KV-32FS10/34FV10/36FS10 only)
* A-1394-943-A UY BOARD, COMPLETE
(KV-32FV15/36FV15 only)
* A-1394-944-A UY BOARD, COMPLETE
(KV-34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
CAPACITOR
C201 1-128-551-11 ELECT 22µF 20% 25V
C202 1-128-551-11 ELECT 22µF 20% 25V
C203 1-128-551-11 ELECT 22µF 20% 25V
C204 1-126-960-11 ELECT 1µF 20% 50V
C205 1-126-960-11 ELECT 1µF 20% 50V
C231 1-163-021-91 CERAMIC 0.01µF 10% 50V
C232 1-126-933-11 ELECT 100µF 20% 16V
C233 1-126-933-11 ELECT 100µF 20% 16V
C234 1-126-960-11 ELECT 1µF 20% 50V
C235 1-126-960-11 ELECT 1µF 20% 50V
C236 1-126-933-11 ELECT 100µF 20% 16V
C237 1-126-9600-11 ELECT 1µF 20% 50V
C238 1-126-960-11 ELECT 1µF 20% 50V
C241 1-126-941-11 ELECT 470µF 20% 25V
C242 1-126-959-11 ELECT 0.47µF 20% 50V
C243 1-126-959-11 ELECT 0.47µF 20% 50V
C244 1-126-959-11 ELECT 0.47µF 20% 50V
C245 1-126-959-11 ELECT 0.47µF 20% 50V
C264 1-164-004-11 CERAMIC 0.1µF 10% 25V
C268 1-163-021-91 CERAMIC 0.01µF 10% 50V
C269 1-163-021-91 CERAMIC 0.01µF 10% 50V
C272 1-163-231-11 CERAMIC 15pF 5% 50V
C273 1-128-551-11 ELECT 22µF 20% 25V
C277 1-128-551-11 ELECT 22µF 20% 25V
C278 1-128-551-11 ELECT 22µF 20% 25V
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
C279 1-163-021-91 CERAMIC 0.01µF 10% 50V
C281 1-126-933-11 ELECT 100µF 20% 16V
C284 1-126-941-11 ELECT 470µF 20% 25V
C286 1-164-161-11 CERAMIC 0.0022µF 10% 50V
C287 1-164-161-11 CERAMIC 0.0022µF 10% 50V
C1051 1-126-964-11 ELECT 10µF 20% 50V
C1053 1-104-665-11 ELECT 100µF 20% 25V
C1201 1-163-809-11 CERAMIC 0.047µF 10% 25V
C1202 1-163-021-91 CERAMIC 0.01µF 10% 50V
C1203 1-126-960-11 ELECT 1µF 20% 50V
C1204 1-163-809-11 CERAMIC 0.047µF 10% 25V
C1209 1-163-259-91 CERAMIC 220pF 5% 50V
C1210 1-163-259-91 CERAMIC 220pF 5% 50V
C1211 1-126-933-11 ELECT 100µF 20% 16V
C1212 1-126-933-11 ELECT 100µF 20% 16V
C1213 1-126-941-11 ELECT 470µF 20% 25V
C1214 1-163-021-91 CERAMIC 0.01µF 10% 50V
C1215 1-126-960-11 ELECT 1µF 20% 50V
C2000 1-126-941-11 ELECT 470µF 20% 25V
C2002 1-126-933-11 ELECT 100µF 20% 16V
C2007 1-104-665-11 ELECT 100µF 20% 10V
C2008 1-163-038-91 CERAMIC 0.1µF 25V
C2012 1-163-021-91 CERAMIC 0.01µF 10% 50V
C2015 1-163-021-91 CERAMIC 0.01µF 10% 50V
C2045 1-163-237-11 CERAMIC 27pF 5% 50V
C2047 1-126-961-11 ELECT 2.2µF 20% 50V
C2048 1-126-964-11 ELECT 10µF 20% 50V
C2049 1-104-664-11 ELECT 47µF 20% 16V
C2056 1-163-231-11 CERAMIC 15pF 5% 50V
C2060 1-163-031-11 CERAMIC 0.01µF 50V
C2062 1-104-664-11 ELECT 47µF 20% 16V
C2096 1-163-231-11 CERAMIC 15pF 5% 50V
C2097 1-163-231-11 CERAMIC 15pF 5% 50V
C2201 1-126-965-11 ELECT 22µF 20% 50V
C2202 1-126-933-11 ELECT 100µF 20% 16V
C2203 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3556 1-163-038-91 CERAMIC 0.1µF 25V
C3557 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3558 1-126-964-11 ELECT 10µF 20% 50V
C3559 1-163-038-91 CERAMIC 0.1µF 25V
C3560 1-163-038-91 CERAMIC 0.1µF 25V
C3561 1-126-964-11 ELECT 10µF 20% 50V
C3562 1-163-038-91 CERAMIC 0.1µF 25V
C3563 1-163-038-91 CERAMIC 0.1µF 25V
C3564 1-163-038-91 CERAMIC 0.1µF 25V
C3565 1-163-038-91 CERAMIC 0.1µF 25V
C3566 1-126-964-11 ELECT 10µF 20% 50V
C3567 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3568 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3569 1-126-964-11 ELECT 10µF 20% 50V
C3570 1-126-964-11 ELECT 10µF 20% 50V
C3571 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3573 1-163-037-11 CERAMIC 0.022µF 10% 50V
C3574 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3575 1-126-964-11 ELECT 10µF 20% 50V
C3576 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3577 1-126-964-11 ELECT 10µF 20% 50V
C3578 1-163-021-91 CERAMIC 0.01µF 10% 50V
C3579 1-104-664-11 ELECT 47µF 20% 16V
CONNECTOR
CN261 1-564-510-11 PLUG, CONNECTOR 7P
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
CN262 1-691-632-21 CONNECTOR, BOARD TO BOARD
CN263 1-691-632-21 CONNECTOR, BOARD TO BOARD 15P
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
CN264 1-691-632-21 CONNECTOR, BOARD TO BOARD
CN265 1-564-513-11 PLUG, CONNECTOR 10P
UY
UY
