Sony TRINITRON KV-34FV15 - C BOARD COMPLETE PARTS LIST (All Models); G BOARD COMPLETE PARTS LIST (KV-32 FS10;32 FV15;32 XBR250;34 FV15 T;36 FS10;36 FV15;36 XBR250;38 FX250 T Only)

— 97 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
* A-1331-942-A C BOARD, COMPLETE (All Models)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C1750 1-137-528-11 FILM 0.1µF 10% 250V
C1751 1-107-655-11 ELECT 47µF 20% 250V
C1790 1-102-129-00 CERAMIC 0.01µF 10% 50V
C1791 1-126-968-11 ELECT 100µF 20% 50V
C1792 1-102-106-00 CERAMIC 100pF 10% 50V
C1794 1-107-651-11 ELECT 4.7µF 20% 250V
C1795 1-102-074-00 CERAMIC 0.001µF 10% 50V
C1799 1-162-114-00 CERAMIC 0.0047µF 2KV
CONNECTOR
CN1761*1-564-509-11 PLUG, CONNECTOR 6P
CN1764*1-564-508-11 PLUG, CONNECTOR 5P
CN1766 1-695-915-11 TAB (CONTACT)
DIODE
D1790 8-719-991-33 DIODE 1SS133T-77
D1791 8-719-908-03 DIODE GP08D
D1792 8-719-908-03 DIODE GP08D
D1793 8-719-908-03 DIODE GP08D
D1794 8-719-908-03 DIODE GP08D
IC
IC1701
!
8-759-562-43 IC TDA6108JF/N1B
JACK
J1761
!
1-540-071-22 SOCKET, CRT
COIL
L1790 1-412-537-31 INDUCTOR 100µH
TRANSISTOR
Q1790 8-729-119-76 TRANSISTOR 2SA1175-HFE
RESISTOR
R1750 1-247-870-11 CARBON 43K 5% 1/4W
R1751 1-247-807-31 CARBON 100 5% 1/4W
R1752 1-247-807-31 CARBON 100 5% 1/4W
R1753
!
1-247-807-31 CARBON 100 5% 1/4W
R1763 1-260-099-11 CARBON 1K 5% 1/2W
R1764 1-247-807-31 CARBON 100 5% 1/4W
R1773 1-260-099-11 CARBON 1K 5% 1/2W
R1774 1-247-807-31 CARBON 100 5% 1/4W
R1783 1-260-099-11 CARBON 1K 5% 1/2W
R1784 1-247-807-31 CARBON 100 5% 1/4W
R1788 1-216-349-00 METAL OXIDE 1 5% 1W F
R1789 1-249-437-11 CARBON 47K 5% 1/4W
R1792 1-247-815-91 CARBON 220 5% 1/4W
R1793 1-247-866-11 CARBON 30K 5% 1/4W
R1794 1-260-132-11 CARBON 560K 5% 1/2W
R1795 1-260-087-11 CARBON 100 5% 1/2W
R1796
!
1-216-374-00 METAL OXIDE 2.7 5% 2W F
R1797 1-260-123-11 CARBON 100K 5% 1/2W
VARIABLE RESISTOR
RV1761 1-241-714-11 RES, ADJ, METAL FILM 110M
* A-1316-397-A G BOARD, COMPLETE
(KV-32FS10/32FV15/32XBR250/36FS10/36FV15/36XBR250 only)
* A-1316-423-A G BOARD, COMPLETE
(KV-34FV15T/38FX250T only)
1-533-223-11 HOLDER, FUSE
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C601 1-136-346-21 FILM 0.22µF 20% 125V
C602 1-126-964-11 ELECT 10µF 20% 50V
C603
!
1-127-790-51 CERAMIC 1000pF 20% 250V
(KV-32FS10/32FV15/32XBR250/36FS10/36FV15/36XBR250 only)
C603
!
1-127-794-51 CERAMIC 2200pF 20% 250V
(KV-34FV15T/38FX250T only)
C604
!
1-136-346-21 FILM 0.22µF 20% 125V
(KV-32FS10/32FV15/32XBR250/36FS10/36FV15/36XBR250 only)
C604
!
1-136-311-11 FILM 0.47µF 20% 125V
(KV-34FV15T/38FX250T only)
C605
!
1-136-346-21 FILM 0.22µF 20% 125V
(KV-32FS10/32FV15/32XBR250/36FS10/36FV15/36XBR250 only)
C605
!
1-136-311-11 FILM 0.47µF 20% 125V
(KV-34FV15T/38FX250T only)
C606
!
1-117-894-11 ELECT 560µF 20% 250V
C607
!
1-117-894-11 ELECT 560µF 20% 250V
C608 1-107-824-11 CERAMIC 220pF 5% 1KV
C609 1-136-176-00 FILM 0.82µF 5% 50V
C610 1-136-176-00 FILM 0.82µF 5% 50V
C611 1-136-169-00 FILM 0.22µF 5% 50V
C612 1-136-169-00 FILM 0.22µF 5% 50V
C613 1-164-646-11 CERAMIC 2200pF 10% 500V
C614 1-126-963-11 ELECT 4.7µF 20% 50V
C615 1-117-976-11 FILM 0.039µF 5% 800V
C616
!
1-127-790-51 CERAMIC 1000pF 20% 250V
(KV-32FS10/32FV15/32XBR250/36FS10/36FV15/36XBR250 only)
C
G
C
G
COMPLETE PARTS LISTING
