— 98 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
C616
!
1-127-794-51 CERAMIC 2200pF 20% 250V
(KV-34FV15T/38FX250T only)
C618 1-126-968-11 ELECT 100µF 20% 50V
C624 1-126-960-11 ELECT 1µF 20% 50V
C629
!
1-107-652-11 ELECT 10µF 20% 250V
C630 1-130-471-00 MYLAR 0.001µF 5% 50V
C631 1-137-605-11 FILM 0.01µF 10% 250V
C633 1-130-471-00 MYLAR 0.001µF 5% 50V
C634 1-130-467-00 MYLAR 470pF 5% 50V
C635 1-130-471-00 MYLAR 0.001µF 5% 50V
C636 1-126-965-11 ELECT 22µF 20% 50V
C637 1-126-940-11 ELECT 330µF 20% 25V
C641 1-128-550-11 ELECT 2200µF 20% 50V
C643 1-107-995-11 ELECT 100µF 0 160V
C644 1-104-664-11 ELECT 47µF 20% 25V
C647 1-104-665-11 ELECT 100µF 20% 25V
C650 1-104-664-11 ELECT 47µF 20% 25V
C651 1-130-477-00 MYLAR 0.0033µF 5% 50V
C652 1-106-351-00 MYLAR 0.0022µF 20% 200V
C653 1-107-636-11 ELECT 10µF 20% 160V
C656 1-126-964-11 ELECT 10µF 20% 50V
C657 1-137-372-11 FILM 0.022µF 5% 50V
C658 1-126-941-11 ELECT 470µF 20% 25V
C660 1-126-936-11 ELECT 3300µF 20% 16V
C661 1-104-664-11 ELECT 47µF 20% 25V
C662 1-126-933-11 ELECT 100µF 20% 16V
C665 1-104-664-11 ELECT 47µF 20% 25V
C695 1-164-625-11 CERAMIC 680pF 10% 500V
C696 1-164-625-11 CERAMIC 680pF 10% 500V
C697 1-164-625-11 CERAMIC 680pF 10% 500V
C698 1-164-625-11 CERAMIC 680pF 10% 500V
C699 1-136-169-00 FILM 0.22µF 5% 50V
CONNECTOR
CN601 * 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
CN602 * 1-580-844-11 PIN, CONNECTOR (POWER)
CN603 * 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
CN641 * 1-564-515-11 PLUG, CONNECTOR 12P
CN642 * 1-564-509-11 PLUG, CONNECTOR 6P
CN643 * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN645 1-695-915-11 TAB (CONTACT)
CN646 1-695-915-11 TAB (CONTACT)
DIODE
D600 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
D602
!
8-719-510-53 DIODE D4SB60L
D603 8-719-063-70 DIODE D1NL20U
D604 8-719-991-33 DIODE 1SS133T-77
D605 8-719-923-83 DIODE MTZJ-T-77-13A
D606 8-719-110-60 DIODE RD24ESB
D607 8-719-109-97 DIODE RD6.8ESB2
D608 8-719-109-97 DIODE RD6.8ESB2
D612 8-719-991-33 DIODE 1SS133T-77
D613 8-719-991-33 DIODE 1SS133T-77
D614 8-719-991-33 DIODE 1SS133T-77
D621 8-719-911-55 DIODE U05G
D622 8-719-911-55 DIODE U05G
D623 8-719-948-45 DIODE ERA22-08
D624 8-719-991-33 DIODE 1SS133T-77
D625 8-719-991-33 DIODE 1SS133T-77
D626 8-719-109-93 DIODE RD6.2ESB2
D627 8-719-510-48 DIODE D1N20R
D628 8-719-510-02 DIODE D1NS4
D629 8-719-052-90 DIODE D1NL40-TA2
D630 8-719-052-90 DIODE D1NL40-TA2
D641 8-719-060-89 DIODE D4SBS6-F
D642 8-719-510-12 DIODE D10SC4M
D643 8-719-062-40 DIODE D4SBL20UF3
D647 8-719-063-70 DIODE D1NL20U
D648
!
8-719-057-52 DIODE EZ0150AV1
D651 8-719-510-02 DIODE D1NS4
D652 8-719-510-02 DIODE D1NS4
D653 8-719-991-33 DIODE 1SS133T-77
D698 8-719-991-33 DIODE 1SS133T-77
D699 8-719-923-86 DIODE MTZJ-T-77-15
FUSE
F601
!
1-532-506-51 FUSE 6.3A/250V
FERRITE BEAD
FB601 1-410-396-41 FERRITE 0.45µH
FB602 1-410-396-41 FERRITE 0.45µH
FB603 1-410-396-41 FERRITE 0.45µH
FB604 1-410-396-41 FERRITE 0.45µH
FB641 1-410-397-21 FERRITE 1.1µH
FB642 1-410-397-21 FERRITE 1.1µH
FB645 1-410-397-21 FERRITE 1.1µH
FB647 1-410-397-21 FERRITE 1.1µH
IC
IC601
!
8-729-045-41 TRANSISTOR MX0842B-F
IC622 8-759-450-47 IC BA05T
IC641 8-759-198-03 IC PQ09RF21
IC643 1-810-051-11 POWER MODULE DM-48
IC650 8-759-394-35 IC BA12T
IC651 8-759-450-47 IC BA05T
COIL
L642 1-412-529-11 INDUCTOR 22µH
L650 1-412-519-11 INDUCTOR 3.3µH
L651 1-412-519-11 INDUCTOR 3.3µH
L652 1-412-519-11 INDUCTOR 3.3µH
G
