Sony TRINITRON KV-34FV15 - Accessories and Packing Material

— 123 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
R2975 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R2976 1-216-025-91 RES, CHIP 100 5% 1/10W
R2979 1-216-097-91 RES, CHIP 100K 5% 1/10W
R2980 1-216-097-91 RES, CHIP 100K 5% 1/10W
VARIABLE RESISTOR
RV941 1-238-019-11 RES, ADJ, CARBON 47K
ACCESSORIES AND PACKING MATERIAL
3-866-305-21 MANUAL, INSTRUCTION (English)
(KV-32FS10/32FV15/32XBR250/36FS10/36FV15 only)
3-866-305-31 MANUAL, INSTRUCTION (French)
(KV-32FS10/32FV15/32XBR250/36FS10/36FV15/36XBR250 only)
3-866-305-41 MANUAL, INSTRUCTION (Spanish)
(KV-34FV10/34FV15/34FV15C34FX250C/38FX250/38FX250C only)
3-866-853-21 MANUAL, INSTRUCTION
(KV-36XBR250 only)
3-866-931-61 MANUAL, INSTRUCTION
(KV-34FV15K/38FV15K only)
3-866-936-71 MANUAL, INSTRUCTION
(KV-34FV15T/38FX250T only)
4-041-259-01 PROTECTION BAG
(KV-32FS10/34FV15K/34FV15T only)
4-053-658-01 PROTECTION BAG
(KV-32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C only)
4-066-646-01 PROTECTION BAG
(KV-36FS10/36FV15/36XBR250/38FV15K/38FX250/38FX250C/
38FX250T only)
4-068-789-01 CUSHION ASSY, LOWER
(KV-32FV15/32XBR250/34FV15K/34FV15T only)
4-068-789-11 CUSHION ASSY, LOWER
(KV-32FS10/34FV10/34FV15/34FV15C only)
4-068-884-01 CUSHION ASSY, LOWER (KV-36FS10 only)
4-069-389-01 CUSHION ASSY, LOWER
(KV-34FX250C/36FV15/36XBR250/38FV15K/38FX250/38FX250C/
38FX250T only)
4-068-786-01 CUSHION ASSY, UPPER
(KV-32FV15/32XBR250/34FV15K/34FV15T/34FX250C only)
4-068-786-11 CUSHION ASSY, UPPER
(KV-32FS10/34FV10/34FV15/34FV15C only)
4-068-883-01 CUSHION ASSY, UPPER (KV-36FS10 only)
4-069-390-01 CUSHION ASSY, UPPER
(KV-36FV15/36XBR250/38FV15K/38FX250/38FX250C/38FX250T only)
4-069-471-01 CARTON
(KV-32FV15/34FV15K/34FV15T only)
4-069-471-11 CARTON
(KV-32FS10/34FV10/34FV15/34FV15C only)
4-069-515-01 CARTON
(KV-36FS10/36FV15/38FV15K/38FX250/38FX250C/38FX250Tonly)
4-070-553-01 CARTON
(KV-32XBR250/34FX250C only)
4-071-107-01 CARTON (KV-36XBR250 only)
REMOTE COMMANDER
1-418-387-11 REMOTE COMMANDER (RM-Y168)
(KV-32FS10/34FV10/36FS10 only)
1-418-465-11 REMOTE COMMANDER (RM-Y170)
(KV-32XBR250/34FX250C/36XBR250/38FX250/38FX250C/
38FX250T only)
1-418-496-11 REMOTE COMMANDER (RM-Y171)
(KV-32FV15/34FV15/34FV15C/34FV15K/34FV15T/36FV15 only)
1-475-069-21 REMOTE COMMANDER (RM-Y149A)
(KV-38FV15K only)
4-978-977-01 BATTERY COVER (for remote)
(RM-Y149A/RM-Y168/RM-Y170/RM-Y171)
