Sony TRINITRON KV-34FV15 - UX BOARD MAIN PARTS LIST (KV-32 XBR250;34 FX250 C;36 XBR250;38 FX250;38 FX250 C;38 FX250 T Only)

— 106 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
MAIN SCHEMATIC (FOR UX PIP COMPONENTS SEE PAGE 112 )
* A-1394-947-A UX BOARD, COMPLETE
(KV-32XBR250/36XBR250 only)
* A-1394-948-A UX BOARD, COMPLETE
(KV-34FX250C/38FX250/38FX250C/38FX250T only)
CAPACITOR
C201 1-128-551-11 ELECT 22µF 20% 25V
C202 1-128-551-11 ELECT 22µF 20% 25V
C203 1-128-551-11 ELECT 22µF 20% 25V
C204 1-126-960-11 ELECT 1µF 20% 50V
C205 1-126-960-11 ELECT 1µF 20% 50V
C231 1-163-021-91 CERAMIC 0.01µF 10% 50V
C232 1-126-933-11 ELECT 100µF 20% 16V
C233 1-126-933-11 ELECT 100µF 20% 16V
C234 1-126-960-11 ELECT 1µF 20% 50V
C235 1-126-960-11 ELECT 1µF 20% 50V
C236 1-126-933-11 ELECT 100µF 20% 16V
C237 1-126-960-11 ELECT 1µF 20% 50V
C238 1-126-960-11 ELECT 1µF 20% 50V
C241 1-126-941-11 ELECT 470µF 20% 25V
C242 1-126-959-11 ELECT 0.47µF 20% 50V
C243 1-126-959-11 ELECT 0.47µF 20% 50V
C244 1-126-959-11 ELECT 0.47µF 20% 50V
C245 1-126-959-11 ELECT 0.47µF 20% 50V
C247 1-126-941-11 ELECT 470µF 20% 25V
C248 1-126-959-11 ELECT 0.47µF 20% 50V
C249 1-126-959-11 ELECT 0.47µF 20% 50V
C264 1-164-004-11 CERAMIC 0.1µF 10% 25V
C268 1-163-021-91 CERAMIC 0.01µF 10% 50V
C269 1-163-021-91 CERAMIC 0.01µF 10% 50V
C272 1-163-231-11 CERAMIC 15pF 5% 50V
C273 1-128-551-11 ELECT 22µF 20% 25V
C277 1-128-551-11 ELECT 22µF 20% 25V
C278 1-128-551-11 ELECT 22µF 20% 25V
C281 1-126-933-11 ELECT 100µF 20% 16V
C284 1-126-941-11 ELECT 470µF 20% 25V
C286 1-164-161-11 CERAMIC 0.0022µF 10% 50V
C287 1-164-161-11 CERAMIC 0.0022µF 10% 50V
C1051 1-126-964-11 ELECT 10µF 20% 50V
C1053 1-104-665-11 ELECT 100µF 20% 25V
C1201 1-163-809-11 CERAMIC 0.047µF 10% 25V
C1202 1-163-021-91 CERAMIC 0.01µF 10% 50V
C1203 1-126-960-11 ELECT 1µF 20% 50V
C1204 1-163-809-11 CERAMIC 0.047µF 10% 25V
C1205 1-126-933-11 ELECT 100µF 20% 16V
C1207 1-126-963-11 ELECT 4.7µF 20% 50V
C1208 1-126-963-11 ELECT 4.7µF 20% 50V
C1209 1-163-259-91 CERAMIC 220pF 5% 50V
C1210 1-163-259-91 CERAMIC 220pF 5% 50V
C1211 1-126-933-11 ELECT 100µF 20% 16V
C1212 1-126-933-11 ELECT 100µF 20% 16V
C1213 1-126-941-11 ELECT 470µF 20% 25V
C1214 1-163-021-91 CERAMIC 0.01µF 10% 50V
C1215 1-126-960-11 ELECT 1µF 20% 50V
C2000 1-126-941-11 ELECT 470µF 20% 25V
C2001 1-163-235-11 CERAMIC 22pF 5% 50V
C2002 1-165-319-11 CERAMIC 0.1µF 50V
C2003 1-163-031-11 CERAMIC 0.01µF 50V
C2004 1-163-235-11 CERAMIC 22pF 5% 50V
C2005 1-163-131-00 CERAMIC 390pF 5% 50V
C2006 1-163-038-91 CERAMIC 0.1µF 25V
C2007 1-126-926-11 ELECT 1000µF 20% 10V
C2008 1-163-038-91 CERAMIC 0.1µF 25V
C2009 1-163-102-00 CERAMIC 24pF 5% 50V
C2012 1-163-031-11 CERAMIC 0.01µF 50V
C2013 1-163-038-91 CERAMIC 0.1µF 25V
C2014 1-163-009-11 CERAMIC 0.001µF 10% 50V
C2015 1-163-021-91 CERAMIC 0.01µF 10% 50V
C2016 1-165-319-11 CERAMIC 0.1µF 50V
C2017 1-163-102-00 CERAMIC 24pF 5% 50V
C2018 1-165-319-11 CERAMIC 0.1µF 50V
C2019 1-126-960-11 ELECT 1µF 20% 50V
C2020 1-165-319-11 CERAMIC 0.1µF 50V
C2021 1-163-038-91 CERAMIC 0.1µF 25V
C2022 1-126-933-11 ELECT 100µF 20% 16V
C2029 1-165-319-11 CERAMIC 0.1µF 50V
C2030 1-165-319-11 CERAMIC 0.1µF 50V
C2031 1-165-319-11 CERAMIC 0.1µF 50V
C2032 1-165-319-11 CERAMIC 0.1µF 50V
C2033 1-165-319-11 CERAMIC 0.1µF 50V
C2034 1-165-319-11 CERAMIC 0.1µF 50V
C2035 1-165-319-11 CERAMIC 0.1µF 50V
C2036 1-165-319-11 CERAMIC 0.1µF 50V
C2038 1-165-319-11 CERAMIC 0.1µF 50V
C2041 1-104-665-11 ELECT 100µF 20% 25V
C2042 1-165-319-11 CERAMIC 0.1µF 50V
C2044 1-104-664-11 ELECT 47µF 20% 16V
C2045 1-163-233-11 CERAMIC 18pF 5% 50V
C2046 1-126-964-11 ELECT 10µF 20% 50V
C2047 1-126-961-11 ELECT 2.2µF 20% 50V
C2048 1-126-964-11 ELECT 10µF 20% 50V
C2050 1-163-231-11 CERAMIC 15pF 5% 50V
C2051 1-126-964-11 ELECT 10µF 20% 50V
C2052 1-163-133-00 CERAMIC 470pF 5% 50V
C2053 1-126-960-11 ELECT 1µF 20% 50V
C2054 1-104-664-11 ELECT 47µF 20% 16V
C2057 1-163-031-11 CERAMIC 0.01µF 50V
C2058 1-163-235-11 CERAMIC 22pF 5% 50V
C2060 1-163-031-11 CERAMIC 0.01µF 50V
C2062 1-104-664-11 ELECT 47µF 20% 16V
C2063 1-165-319-11 CERAMIC 0.1µF 50V
C2064 1-163-031-11 CERAMIC 0.01µF 50V
C2065 1-163-031-11 CERAMIC 0.01µF 50V
C2066 1-104-664-11 ELECT 47µF 20% 16V
C2067 1-104-664-11 ELECT 47µF 20% 16V
