REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
C2068 1-104-664-11 ELECT 47µF 20% 16V
C2069 1-163-031-11 CERAMIC 0.01µF 50V
C2070 1-104-664-11 ELECT 47µF 20% 16V
C2071 1-165-319-11 CERAMIC 0.1µF 50V
C2072 1-126-933-11 ELECT 100µF 20% 16V
C2073 1-163-275-11 CERAMIC 0.001µF 5% 50V
C2074 1-163-275-11 CERAMIC 0.001µF 5% 50V
C2081 1-126-960-11 ELECT 1µF 20% 50V
C2082 1-165-319-11 CERAMIC 0.1µF 50V
C2083 1-163-031-11 CERAMIC 0.01µF 50V
C2084 1-126-964-11 ELECT 10µF 20% 50V
C2085 1-163-031-11 CERAMIC 0.01µF 50V
C2086 1-126-961-11 ELECT 2.2µF 20% 50V
C2087 1-165-319-11 CERAMIC 0.1µF 50V
C2088 1-163-031-11 CERAMIC 0.01µF 50V
C2089 1-126-967-11 ELECT 47µF 20% 50V
C2090 1-165-319-11 CERAMIC 0.1µF 50V
C2091 1-126-964-11 ELECT 10µF 20% 50V
C2095 1-163-231-11 CERAMIC 15pF 5% 50V
C2096 1-163-231-11 CERAMIC 15pF 5% 50V
C2097 1-163-231-11 CERAMIC 15pF 5% 50V
C2139 1-163-113-00 CERAMIC 68pF 5% 50V
C2154 1-104-664-11 ELECT 47µF 20% 16V
C2167 1-126-964-11 ELECT 10µF 20% 50V
C2201 1-126-965-11 ELECT 22µF 20% 50V
C2202 1-126-933-11 ELECT 100µF 20% 16V
C2203 1-163-021-91 CERAMIC 0.01µF 10% 50V
CONNECTOR
CN261 1-564-510-11 PLUG, CONNECTOR 7P
CN262 1-691-632-21 CONNECTOR, BOARD TO BOARD15P
CN263 1-691-632-21 CONNECTOR, BOARD TO BOARD15P
CN264 1-691-632-21 CONNECTOR, BOARD TO BOARD15P
CN265 1-564-513-11 PLUG, CONNECTOR 10P
DIODE
D201 8-719-032-47 DIODE MTZJ-T-9110
D202 8-719-032-47 DIODE MTZJ-T-9110
D203 8-719-032-47 DIODE MTZJ-T-9110
D204 8-719-032-47 DIODE MTZJ-T-9110
D205 8-719-032-47 DIODE MTZJ-T-9110
D231 8-719-032-47 DIODE MTZJ-T-9110
D232 8-719-032-47 DIODE MTZJ-T-9110
D233 8-719-032-47 DIODE MTZJ-T-9110
D234 8-719-032-47 DIODE MTZJ-T-9110
D235 8-719-032-47 DIODE MTZJ-T-9110
D236 8-719-032-47 DIODE MTZJ-T-9110
D237 8-719-032-47 DIODE MTZJ-T-9110
D238 8-719-032-47 DIODE MTZJ-T-9110
D239 8-719-032-47 DIODE MTZJ-T-9110
D245 8-719-157-94 DIODE RD3.3SB
D246 8-719-157-94 DIODE RD3.3SB
D247 8-719-157-94 DIODE RD3.3SB
D248 8-719-157-94 DIODE RD3.3SB
D249 8-719-157-94 DIODE RD3.3SB
D250 8-719-157-94 DIODE RD3.3SB
D261 8-719-032-47 DIODE MTZJ-T-9110
D902 8-719-032-47 DIODE MTZJ-T-9110
D910 8-719-032-47 DIODE MTZJ-T-9110
D911 8-719-032-47 DIODE MTZJ-T-9110
D912 8-719-032-47 DIODE MTZJ-T-9110
D1051 8-719-404-50 DIODE MA111-TX
D1052 8-719-404-50 DIODE MA111-TX
D2005 8-719-404-50 DIODE MA111-TX
D2201 8-719-032-47 DIODE MTZJ-T-9110
D2202 8-719-032-47 DIODE MTZJ-T-9110
D2203 8-719-032-47 DIODE MTZJ-T-9110
FERRITE BEAD
FB2001 1-414-234-22 INDUCTOR
FB2002 1-414-234-22 INDUCTOR
FB2003 1-414-234-22 INDUCTOR
FB2004 1-414-230-22 INDUCTOR
FB2005 1-414-230-22 INDUCTOR
FB2009 1-414-233-22 INDUCTOR
FB2029 1-216-295-91 SHORT
FB2101 1-216-295-91 SHORT
FILTER
FL2001 1-239-847-11 FILTER, LOW PASS
FL2002 1-239-847-11 FILTER, LOW PASS
FL2003 1-239-847-11 FILTER, LOW PASS
FL2004 1-239-847-11 FILTER, LOW PASS
IC
IC261 8-752-066-69 IC CXA1845Q
IC1051 8-752-058-68 IC CXA1315M
IC2003 8-759-568-27 IC MSM514265C-60JSDR1
IC2004 8-759-536-12 IC UPD64081BGF-3BA
IC2005 8-759-591-79 IC UPC2933T-E1
IC2006 8-759-358-38 IC NJM78M05DLA(TE1)
IC2007 8-759-161-24 IC UPC659AGS-E2
IC2009 8-752-395-12 IC CXD2085M
JACK
J231 1-750-515-11 TERMINAL BLOCK, S 3P
J232 1-750-517-11 JACK BLOCK, PIN 3P
J233 1-750-516-11 JACK BLOCK, PIN 2P
J234 1-750-517-11 JACK BLOCK, PIN 3P
J235 1-750-517-11 JACK BLOCK, PIN 3P
J236 1-774-358-11 JACK BLOCK, PIN
J902 1-764-143-11 JACK 3P
UX
