REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
J903 1-764-143-11 JACK 3P
J904 1-764-143-11 JACK 3P
J905 1-764-143-11 JACK 3P
CHIP CONDUCTOR
JR1001 1-216-295-91 SHORT
JR1002 1-216-295-91 SHORT
JR1003 1-216-295-91 SHORT
JR1004 1-216-295-91 SHORT
JR1021 1-216-295-91 SHORT
JR1022 1-216-295-91 SHORT
JR1023 1-216-295-91 SHORT
JR2007 1-216-295-91 SHORT
JR2008 1-216-295-91 SHORT
JR2009 1-216-295-91 SHORT
JR2010 1-216-295-91 SHORT
JR2011 1-216-295-91 SHORT
JR2012 1-216-295-91 SHORT
JR2013 1-216-295-91 SHORT
JR2014 1-216-295-91 SHORT
COIL
L261 1-414-857-11 INDUCTOR 100µH
L1201 1-408-397-00 INDUCTOR 1µH
L1202 1-408-397-00 INDUCTOR 1µH
L1203 1-408-397-00 INDUCTOR 1µH
L2001 1-410-466-41 INDUCTOR 4.7µH
L2002 1-414-856-11 INDUCTOR 10µH
L2003 1-414-856-11 INDUCTOR 10µH
L2004 1-410-473-11 INDUCTOR 18µH
L2006 1-414-856-11 INDUCTOR 10µH
L2007 1-414-857-11 INDUCTOR 100µH
L2008 1-414-856-11 INDUCTOR 10µH
L2009 1-414-856-11 INDUCTOR 10µH
L2010 1-410-494-11 INDUCTOR 1mH
L2011 1-410-116-11 INDUCTOR 560µH
L2012 1-410-116-11 INDUCTOR 560µH
L2013 1-410-462-11 INDUCTOR 2.2µH
L2014 1-410-462-11 INDUCTOR 2.2µH
TRANSISTOR
Q202 8-729-422-27 TRANSISTOR 2SD601A-Q
Q203 8-729-422-27 TRANSISTOR 2SD601A-Q
Q205 8-729-216-22 TRANSISTOR 2SA1162-G
Q206 8-729-216-22 TRANSISTOR 2SA1162-G
Q208 8-729-422-27 TRANSISTOR 2SD601A-Q
Q209 8-729-422-27 TRANSISTOR 2SD601A-Q
Q210 8-729-422-27 TRANSISTOR 2SD601A-Q
Q211 8-729-422-27 TRANSISTOR 2SD601A-Q
Q231 8-729-422-27 TRANSISTOR 2SD601A-Q
Q233 8-729-422-27 TRANSISTOR 2SD601A-Q
Q234 8-729-422-27 TRANSISTOR 2SD601A-Q
Q235 8-729-422-27 TRANSISTOR 2SD601A-Q
Q236 8-729-422-27 TRANSISTOR 2SD601A-Q
Q237 8-729-216-22 TRANSISTOR 2SA1162-G
Q238 8-729-216-22 TRANSISTOR 2SA1162-G
Q239 8-729-216-22 TRANSISTOR 2SA1162-G
Q240 8-729-422-27 TRANSISTOR 2SD601A-Q
Q241 8-729-422-27 TRANSISTOR 2SD601A-Q
Q242 8-729-422-27 TRANSISTOR 2SD601A-Q
Q243 8-729-216-22 TRANSISTOR 2SA1162-G
Q244 8-729-216-22 TRANSISTOR 2SA1162-G
Q245 8-729-216-22 TRANSISTOR 2SA1162-G
Q246 8-729-422-27 TRANSISTOR 2SD601A-Q
Q262 8-729-216-22 TRANSISTOR 2SA1162-G
Q263 8-729-216-22 TRANSISTOR 2SA1162-G
Q264 8-729-216-22 TRANSISTOR 2SA1162-G
Q265 8-729-422-27 TRANSISTOR 2SD601A-Q
Q267 8-729-216-22 TRANSISTOR 2SA1162-G
Q268 8-729-216-22 TRANSISTOR 2SA1162-G
Q1051 8-729-216-22 TRANSISTOR 2SA1162-G
Q1201 8-729-216-22 TRANSISTOR 2SA1162-G
Q1202 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1203 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1204 8-729-216-22 TRANSISTOR 2SA1162-G
Q1205 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1206 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1207 8-729-216-22 TRANSISTOR 2SA1162-G
Q1208 8-729-216-22 TRANSISTOR 2SA1162-G
Q1405 8-729-216-22 TRANSISTOR 2SA1162-G
Q1406 8-729-216-22 TRANSISTOR 2SA1162-G
Q2001 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2003 8-729-216-22 TRANSISTOR 2SA1162-G
Q2004 8-729-216-22 TRANSISTOR 2SA1162-G
Q2005 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2006 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2007 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2008 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2009 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2010 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2011 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2012 8-729-216-22 TRANSISTOR 2SA1162-G
Q2013 8-729-216-22 TRANSISTOR 2SA1162-G
Q2014 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2015 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2016 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2017 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2018 8-729-216-22 TRANSISTOR 2SA1162-G
Q2019 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2119 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R201 1-216-022-00 RES, CHIP 75 5% 1/10W
R202 1-216-022-00 RES, CHIP 75 5% 1/10W
R203 1-216-022-00 RES, CHIP 75 5% 1/10W
