Sony TRINITRON KV-34FV15 - Page 75

— 109 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
R204 1-216-113-00 RES, CHIP 470K 5% 1/10W
R205 1-216-113-00 RES, CHIP 470K 5% 1/10W
R206 1-216-295-91 SHORT
R207 1-216-295-91 SHORT
R208 1-216-295-91 SHORT
R209 1-216-089-91 RES, CHIP 47K 5% 1/10W
R210 1-216-081-00 RES, CHIP 22K 5% 1/10W
R211 1-216-089-91 RES, CHIP 47K 5% 1/10W
R212 1-216-081-00 RES, CHIP 22K 5% 1/10W
R213 1-216-089-91 RES, CHIP 47K 5% 1/10W
R214 1-216-081-00 RES, CHIP 22K 5% 1/10W
R218 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R219 1-216-049-91 RES, CHIP 1K 5% 1/10W
R220 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R221 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R222 1-216-049-91 RES, CHIP 1K 5% 1/10W
R223 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R225 1-216-025-91 RES, CHIP 100 5% 1/10W
R226 1-216-025-91 RES, CHIP 100 5% 1/10W
R228 1-216-049-91 RES, CHIP 1K 5% 1/10W
R229 1-216-049-91 RES, CHIP 1K 5% 1/10W
R230 1-216-089-91 RES, CHIP 47K 5% 1/10W
R231 1-216-022-00 RES, CHIP 75 5% 1/10W
R232 1-216-022-00 RES, CHIP 75 5% 1/10W
R233 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R234 1-216-022-00 RES, CHIP 75 5% 1/10W
R235 1-216-113-00 RES, CHIP 470K 5% 1/10W
R236 1-216-113-00 RES, CHIP 470K 5% 1/10W
R237 1-216-022-00 RES, CHIP 75 5% 1/10W
R238 1-216-113-00 RES, CHIP 470K 5% 1/10W
R239 1-216-113-00 RES, CHIP 470K 5% 1/10W
R241 1-216-113-00 RES, CHIP 470K 5% 1/10W
R242 1-216-049-91 RES, CHIP 1K 5% 1/10W
R243 1-216-113-00 RES, CHIP 470K 5% 1/10W
R244 1-216-049-91 RES, CHIP 1K 5% 1/10W
R245 1-216-022-00 RES, CHIP 75 5% 1/10W
R246 1-216-113-00 RES, CHIP 470K 5% 1/10W
R247 1-216-113-00 RES, CHIP 470K 5% 1/10W
R248 1-216-113-00 RES, CHIP 470K 5% 1/10W
R249 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R250 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R251 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R252 1-216-049-91 RES, CHIP 1K 5% 1/10W
R254 1-216-049-91 RES, CHIP 1K 5% 1/10W
R256 1-216-295-91 SHORT
R257 1-216-049-91 RES, CHIP 1K 5% 1/10W
R258 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R259 1-216-049-91 RES, CHIP 1K 5% 1/10W
R260 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R261 1-216-025-91 RES, CHIP 100 5% 1/10W
R262 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R263 1-216-025-91 RES, CHIP 100 5% 1/10W
R264 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R265 1-216-025-91 RES, CHIP 100 5% 1/10W
R266 1-216-025-91 RES, CHIP 100 5% 1/10W
R267 1-216-025-91 RES, CHIP 100 5% 1/10W
R268 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R269 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R270 1-216-049-91 RES, CHIP 1K 5% 1/10W
R271 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R272 1-216-025-91 RES, CHIP 100 5% 1/10W
R273 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R274 1-216-049-91 RES, CHIP 1K 5% 1/10W
R275 1-216-025-91 RES, CHIP 100 5% 1/10W
R276 1-216-295-91 SHORT
R278 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R279 1-216-025-91 RES, CHIP 100 5% 1/10W
R280 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R281 1-216-025-91 RES, CHIP 100 5% 1/10W
R282 1-216-025-91 RES, CHIP 100 5% 1/10W
R283 1-216-049-91 RES, CHIP 1K 5% 1/10W
R284 1-216-033-00 RES, CHIP 220 5% 1/10W
R285 1-216-033-00 RES, CHIP 220 5% 1/10W
R286 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R287 1-216-025-91 RES, CHIP 100 5% 1/10W
R288 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R289 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R290 1-216-025-91 RES, CHIP 100 5% 1/10W
R291 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R293 1-216-025-91 RES, CHIP 100 5% 1/10W
R294 1-216-077-00 RES, CHIP 15K 5% 1/10W
R295 1-216-025-91 RES, CHIP 100 5% 1/10W
R296 1-216-025-91 RES, CHIP 100 5% 1/10W
R297 1-216-025-91 RES, CHIP 100 5% 1/10W
R300 1-216-025-91 RES, CHIP 100 5% 1/10W
R301 1-216-049-91 RES, CHIP 1K 5% 1/10W
R302 1-216-295-91 SHORT
R902 1-249-405-11 CARBON 100 5% 1/4W F
R921 1-249-405-11 CARBON 100 5% 1/4W F
R923 1-249-405-11 CARBON 100 5% 1/4W F
R925 1-249-405-11 CARBON 100 5% 1/4W F
R926 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1051 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1052 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1054 1-216-025-91 RES, CHIP 100 5% 1/10W
R1055 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1056 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1057 1-216-025-91 RES, CHIP 100 5% 1/10W
R1058 1-216-025-91 RES, CHIP 100 5% 1/10W
R1059 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1060 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1062 1-216-025-91 RES, CHIP 100 5% 1/10W
R1063 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1064 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1065 1-216-025-91 RES, CHIP 100 5% 1/10W
R1070 1-216-025-91 RES, CHIP 100 5% 1/10W
R1201 1-216-025-91 RES, CHIP 100 5% 1/10W
R1202 1-216-025-91 RES, CHIP 100 5% 1/10W
R1204 1-216-295-91 SHORT
R1206 1-216-295-91 SHORT
