Sony TRINITRON KV-34FV15 - Page 76

— 110 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
R1208 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1209 1-216-295-91 SHORT
R1210 1-216-295-91 SHORT
R1212 1-216-295-91 SHORT
R1213 1-216-295-91 SHORT
R1214 1-216-295-91 SHORT
R1215 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R1216 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R1217 1-216-091-00 RES, CHIP 56K 5% 1/10W
R1219 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1220 1-216-013-00 RES, CHIP 33 5% 1/10W
R1221 1-216-121-91 RES, CHIP 1M 5% 1/10W
R1222 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1223 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1224 1-216-089-91 RES, CHIP 47K 5% 1/10W
R1225 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1227 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1228 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R1229 1-216-121-91 RES, CHIP 1M 5% 1/10W
R1230 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1231 1-216-295-91 SHORT
R1233 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1234 1-216-091-00 RES, CHIP 56K 5% 1/10W
R1235 1-216-013-00 RES, CHIP 33 5% 1/10W
R1236 1-216-097-91 RES, CHIP 100K 5% 1/10W
R1237 1-216-089-91 RES, CHIP 47K 5% 1/10W
R1238 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R1240 1-216-295-91 SHORT
R1242 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1243 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1244 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1245 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1246 1-216-022-00 RES, CHIP 75 5% 1/10W
R1247 1-216-113-00 RES, CHIP 470K 5% 1/10W
R1248 1-216-113-00 RES, CHIP 470K 5% 1/10W
R1249 1-216-113-00 RES, CHIP 470K 5% 1/10W
R1250 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1251 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1252 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1254 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1255 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1256 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1257 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1258 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1259 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1260 1-216-295-91 SHORT
R1263 1-216-295-91 SHORT
R1264 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1265 1-216-001-00 RES, CHIP 10 5% 1/10W
R1266 1-216-041-00 RES, CHIP 470 5% 1/10W
R1267 1-216-025-91 RES, CHIP 100 5% 1/10W
R1268 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1269 1-216-041-00 RES, CHIP 470 5% 1/10W
R1270 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1271 1-216-001-00 RES, CHIP 10 5% 1/10W
R1272 1-216-655-11 RES, CHIP 1.5K 0.50% 1/10W
R1273 1-208-788-11 RES, CHIP 1.8K 0.50% 1/10W
R1274 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1276 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1277 1-216-025-91 RES, CHIP 100 5% 1/10W
R1278 1-216-025-91 RES, CHIP 100 5% 1/10W
R1279 1-216-025-91 RES, CHIP 100 5% 1/10W
R1280 1-216-025-91 RES, CHIP 100 5% 1/10W
R1287 1-216-295-91 SHORT
R1288 1-216-295-91 SHORT
R1289 1-216-295-91 SHORT
R1290 1-216-295-91 SHORT
R1291 1-216-295-91 SHORT
R1292 1-216-295-91 SHORT
R1293 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1294 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1295 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1296 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1297 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1298 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1299 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1300 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1304 1-216-041-00 RES, CHIP 470 5% 1/10W
R1305 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R1306 1-216-025-91 RES, CHIP 100 5% 1/10W
R1307 1-216-041-00 RES, CHIP 470 5% 1/10W
R1308 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R1309 1-216-025-91 RES, CHIP 100 5% 1/10W
R1422 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1423 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R2001 1-216-073-00 RES, CHIP 10K 5% 1/10W
R2002 1-216-073-00 RES, CHIP 10K 5% 1/10W
R2003 1-216-085-00 RES, CHIP 33K 5% 1/10W
R2004 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R2005 1-216-295-91 SHORT
R2006 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R2008 1-216-025-91 RES, CHIP 100 5% 1/10W
R2009 1-216-025-91 RES, CHIP 100 5% 1/10W
R2010 1-216-001-00 RES, CHIP 10 5% 1/10W
R2011 1-216-041-00 RES, CHIP 470 5% 1/10W
R2012 1-216-025-91 RES, CHIP 100 5% 1/10W
R2013 1-216-081-00 RES, CHIP 22K 5% 1/10W
R2014 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R2015 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R2016 1-208-822-11 RES, CHIP 47K 0.50% 1/10W
R2021 1-216-081-00 RES, CHIP 22K 5% 1/10W
R2022 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2023 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2027 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2028 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2029 1-216-043-91 RES, CHIP 560 5% 1/10W
R2030 1-216-043-91 RES, CHIP 560 5% 1/10W
R2031 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R2032 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R2033 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
