Sony TRINITRON KV-34FV15 - Page 77

— 111 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
R2034 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R2035 1-208-775-11 RES, CHIP 510 0.50% 1/10W
R2036 1-208-775-11 RES, CHIP 510 0.50% 1/10W
R2037 1-216-051-00 RES, CHIP 1.2K 5% 1/10W
R2038 1-216-033-00 RES, CHIP 220 5% 1/10W
R2039 1-216-047-91 RES, CHIP 820 5% 1/10W
R2040 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R2041 1-216-047-91 RES, CHIP 820 5% 1/10W
R2042 1-216-075-00 RES, CHIP 12K 5% 1/10W
R2043 1-216-085-00 RES, CHIP 33K 5% 1/10W
R2044 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R2046 1-216-075-00 RES, CHIP 12K 5% 1/10W
R2047 1-216-085-00 RES, CHIP 33K 5% 1/10W
R2048 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2049 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R2050 1-216-017-91 RES, CHIP 47 5% 1/10W
R2051 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2052 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2053 1-216-041-00 RES, CHIP 470 5% 1/10W
R2054 1-216-041-00 RES, CHIP 470 5% 1/10W
R2055 1-216-017-91 RES, CHIP 47 5% 1/10W
R2056 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R2057 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2058 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R2059 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2060 1-216-025-91 RES, CHIP 100 5% 1/10W
R2061 1-216-043-91 RES, CHIP 560 5% 1/10W
R2062 1-216-105-91 RES, CHIP 220K 5% 1/10W
R2063 1-216-089-91 RES, CHIP 47K 5% 1/10W
R2064 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2065 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2066 1-216-033-00 RES, CHIP 220 5% 1/10W
R2067 1-216-048-00 RES, CHIP 910 5% 1/10W
R2069 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R2070 1-208-777-11 RES, CHIP 620 0.50% 1/10W
R2071 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R2072 1-216-043-91 RES, CHIP 560 5% 1/10W
R2073 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2074 1-216-025-91 RES, CHIP 100 5% 1/10W
R2076 1-216-025-91 RES, CHIP 100 5% 1/10W
R2077 1-216-025-91 RES, CHIP 100 5% 1/10W
R2079 1-216-295-91 SHORT
R2092 1-216-025-91 RES, CHIP 100 5% 1/10W
R2093 1-216-025-91 RES, CHIP 100 5% 1/10W
R2094 1-208-810-11 RES, CHIP 15K 0.50% 1/10W
R2095 1-216-025-91 RES, CHIP 100 5% 1/10W
R2096 1-216-025-91 RES, CHIP 100 5% 1/10W
R2097 1-216-025-91 RES, CHIP 100 5% 1/10W
R2098 1-216-025-91 RES, CHIP 100 5% 1/10W
R2099 1-216-025-91 RES, CHIP 100 5% 1/10W
R2100 1-216-025-91 RES, CHIP 100 5% 1/10W
R2101 1-216-025-91 RES, CHIP 100 5% 1/10W
R2102 1-216-025-91 RES, CHIP 100 5% 1/10W
R2103 1-216-017-91 RES, CHIP 47 5% 1/10W
R2104 1-216-295-91 SHORT
R2105 1-216-295-91 SHORT
R2106 1-216-295-91 SHORT
R2107 1-216-295-91 SHORT
R2113 1-216-017-91 RES, CHIP 47 5% 1/10W
R2115 1-216-049-91 RES, CHIP 1K 5% 1/10W
R2153 1-216-295-91 SHORT
R2157 1-216-295-91 SHORT
R2183 1-216-295-91 SHORT
R2188 1-216-295-91 SHORT
R2201 1-216-022-00 RES, CHIP 75 5% 1/10W
R2202 1-216-022-00 RES, CHIP 75 5% 1/10W
R2203 1-216-022-00 RES, CHIP 75 5% 1/10W
CRYSTAL
X2001 1-767-606-11 VIBRATOR, CRYSTAL
X2002 1-767-367-21 VIBRATOR, CERAMIC
UX
